System And Components
240-1624 GOVERNOR GPS/N E1M1-UP
Group No: 240-1624
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535960 | 3 NUT (M6X1-THD) | 1 | |
| 1537983 | 4 PIN | 1 | |
| 1537987 | 5 WASHER | 1 | |
| 1541396 | 6 CLIP | 1 | |
| 4458964 | 7 ARM | 1 | |
| 0951574 | 8 SEAL-O-RING | 1 | |
| 1541407 | 9 BOLT | 1 | |
| 1541408 | 10 WASHER (8.4X15.5X1.6-MM THK) | 1 | |
| 0951508 | 11 SEAL-O-RING | 2 | |
| 1541411 | 12 CLIP | 1 | |
| 1541412 | 13 BRACKET | 1 | |
| 1541416 | 14 SPRING | 1 | |
| 1541636 | 15 NUT (M8X1.25-THD) | 2 | |
| 1541637 | 16 ARM | 1 | |
| 1048054 | 17 SEAL-O-RING | 1 | |
| 1541639 | 18 CLIP | 1 | |
| 3107139 | 19 SPRING | 1 | |
| 1558009 | 20 BOLT | 1 | |
| 8T4971 | 21 BOLT (M6X1X30-MM) | 2 | |
| 1622207 | 22 NUT | 2 | |
| 1665268 | 23 LEVER | 1 | |
| 1833570 | 24 LEVER | 1 | |
| 2497263 | 25 BOLT (M6X1X16-MM) | 2 | |
| 1910542 | 26 SHAFT | 1 | |
| 1919296 | 27 BOLT | 1 | |
| 1919297 | 28 NUT (M10X1.25-THD) | 1 | |
| 2177111 | 29 BOLT AS | 1 | |
| 1537987 | 29A WASHER | 1 | |
| 2120743 | 29B NUT | 1 | |
| 2120744 | 29C SEAL-O-RING | 1 | |
| 2120745 | 29D BOLT | 1 | |
| 2120747 | 29E RING-RETAINING | 1 | |
| 2177115 | 30 CAP (TAMPER RESISTANT) | 1 | |
| 2366565 | 31 SPRING | 1 | |
| 2560214 | 32 SPRING-MAIN | 1 | |
| 2401623 | 33 LEVER | 1 | |
| 2117739 | 34 KIT-CAP (TAMPER RESISTANT) | 1 |
