System And Components
273-9341 AIR CLEANER & RADIATOR GPS/N E2M1-UP
Group No: 273-9341
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0254 | 2 BOLT (M8X1.25X30-MM) | 2 | |
| 0643058 | 3 CLAMP-HOSE | 4 | |
| 1036714 | 4 CLIP | 2 | |
| 1535592 | 5 NUT (M8X1.25-THD) | 3 | |
| 1536375 | 6 BOLT (M8X1.25X16-MM) | 1 | |
| 6I0917 | 7 BOLT (M6X1X25-MM) | 2 | |
| 1806118 | 8 BOLT (M8X1.25X12-MM) | 9 | |
| 1982664 | 9 BOLT-HEAD (M14X1.5X25-MM) | 8 | |
| 2366610 | 10 MOUNT | 1 | |
| 2380245 | 11 HOSE-AIR CLEANER | 1 | |
| 2380265 | 12 HOSE-RADIATOR (LOWER) | 1 | |
| 2380266 | 13 HOSE-RADIATOR (UPPER) | 1 | |
| 2380271 | 14 RADIATOR AS | 1 | |
| 2026616 | 14A CAP-RADIATOR | 1 | |
| 2955876 | 14B SHROUD | ||
| 2390743 | 15 SUPPORT | 1 | |
| 2390745 | 16 BRACKET-MOUNTING (RADIATOR, RH) | 1 | |
| 2390746 | 17 BRACKET-MOUNTING (RADIATOR, LH) | 1 | |
| 2391137 | 18 BOLT (M10X1.25X25-MM) | 2 | |
| 2443259 | 19 CLIP | 2 | |
| 2471377 | 20 BRACKET-FILTER | 1 | |
| 2471378 | 21 FILTER ELEMENT AS-AIR (TURBOCHARGER) | 1 | |
| 2471380 | 21A FILTER ELEMENT-AIR | 1 | |
| 2715059 | 21B INDICATOR (AIR FILTER SERVICE) | 1 | |
| 2715062 | 21C VALVE-DUST | 1 | |
| 3217701 | 21D BRACKET | 1 | |
| 2698240 | 22 GUARD | 1 | |
| 2698242 | 23 SUPPORT | 1 | |
| 2921992 | 24 SPACER | 1 | |
| 2929909 | 25 GUARD-RADIATOR (RADIATOR, LH) | 1 | |
| 3170681 | 26 GUARD-FAN (RADIATOR, RH) | 1 | |
| 3261010 | 27 CLAMP-HOSE | 1 |
