System And Components
342-8094 GOVERNOR GPS/N C3M876-UP; G8M2290-UP
Group No: 342-8094
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 3 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 4 WASHER | 2 | |
| 1537983 | 5 PIN | 1 | |
| 0951574 | 6 SEAL-O-RING | 1 | |
| 1541407 | 7 BOLT | 1 | |
| 8T4971 | 8 BOLT (M6X1X30-MM) | 1 | |
| 1622207 | 9 NUT | 1 | |
| 2177115 | 10 CAP (TAMPER RESISTANT) | 1 | |
| 1068916 | 11 BOLT (M6X1X16-MM) | 4 | |
| 4237724 | 12 GASKET | 1 | |
| 3081882 | 13 SPRING | 1 | |
| 3081889 | 14 NUT (M10X1.25-THD) | 1 | |
| 3081892 | 15 NUT (M6X1-THD) | 1 | |
| 5029478 | 16 NUT | 1 | |
| 3084266 | 17 SHAFT | 1 | |
| 3903731 | 18 SHAFT | 1 | |
| 3096729 | 19 SEAL-O-RING | 1 | |
| 4950737 | 20 BOLT | 1 | |
| 3110655 | 21 SPRING | 1 | |
| 3132025 | 22 BOLT-SPECIAL (M10X1.25-MM THD) | 1 | |
| 3135832 | 23 BOLT AS | 1 | |
| 1537987 | 23A WASHER | 1 | |
| 1919297 | 23B NUT (M10X1.25-THD) | 1 | |
| 3135833 | 23C SPRING | 1 | |
| 3177195 | 24 SPRING | 1 | |
| 3903729 | 25 LEVER-CONTROL | 1 | |
| 3243398 | 26 LEVER-CONTROL | 1 | |
| 3309189 | 27 PLUG | 1 | |
| 3340732 | 28 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 29 BRACKET | 1 | |
| 3362965 | 30 SPRING | 1 | |
| 5025421 | 31 PIN | 1 | |
| 5039707 | 32 CAP | 1 | |
| 5039731 | 33 SHROUD | 1 | |
| 3081897 | 34 RING | 1 |
