System And Components
452-4501 RADIATOR & FAN GPS/N NP21-UP
Group No: 452-4501
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0654 | 2 BOLT (M10X1.5X25-MM) | 2 | |
| 6I0917 | 3 BOLT (M6X1X25-MM) | 2 | |
| 1243815 | 4 BOLT (M8X1.25X16-MM) | 4 | |
| 2S3440 | 5 CLAMP-HOSE | 4 | |
| 1535592 | 6 NUT (M8X1.25-THD) | 2 | |
| 1535961 | 7 BOLT (M6X1X35-MM) | 4 | |
| 1806118 | 8 BOLT (M8X1.25X12-MM) | 6 | |
| 1978448 | 9 BOLT | 7 | |
| 2440494 | 10 RADIATOR AS | 1 | |
| 2026616 | 10A CAP-RADIATOR | 1 | |
| 2440495 | 11 SUPPORT | 1 | |
| 2440503 | 12 HOSE-RADIATOR | 1 | |
| 2443259 | 13 CLIP | 2 | |
| 2551297 | 14 PLATE | 1 | |
| 2584520 | 15 HOSE-RADIATOR | 1 | |
| 3255924 | 16 GUARD-FAN | 1 | |
| 3255932 | 17 BRACKET | 1 | |
| 3347437 | 18 BRACKET | 1 | |
| 3445868 | 19 MOUNT | 1 | |
| 3662614 | 20 GUARD-ALTERNATOR | 1 | |
| 3662615 | 21 GUARD AS-FAN | 1 | |
| 6I0254 | 21A BOLT (M8X1.25X30-MM) | 3 | |
| 3628050 | 21B NUT (M8X1.25X15-MM) | 3 | |
| 4235640 | 22 FAN | 1 | |
| 4525051 | 23 BRACKET | 1 | |
| 4525052 | 24 BRACKET | 1 |
