System And Components
566-9386 HOUSING GP-FRONTS/N SM81-UP
Group No: 566-9386
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X1X16-MM) | 4 | |
| 5C2890 | 2 NUT (M6X1-THD) | 1 | |
| 1395511 | 3 CAP (TAMPER RESISTANT)(MAX FUEL) | 1 | |
| 1535592 | 4 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 5 WASHER (SEAL) | 2 | |
| 1537983 | 6 PIN | 1 | |
| 0951574 | 7 SEAL-O-RING | 1 | |
| 5D1319 | 8 PIN-SPRING | 1 | |
| 1541675 | 9 SEAL | 1 | |
| 1622207 | 10 NUT (M6X1-THD)(M6X1X13-MM) | 1 | |
| 3081882 | 11 SPRING | 1 | |
| 3081889 | 12 NUT (M10X1.25-THD) | 1 | |
| 3081892 | 13 NUT (M6X1-THD) | 1 | |
| 3081897 | 14 RING | 1 | |
| 3084266 | 15 SHAFT | 1 | |
| 3096729 | 16 SEAL-O-RING | 1 | |
| 3110655 | 17 SPRING | 1 | |
| 3132025 | 18 BOLT-SPECIAL (M10X1.25-MM THD) | 1 | |
| 3155236 | 19 BOLT AS | 1 | |
| 1537987 | 19A WASHER | 1 | |
| 1919297 | 19B NUT (M10X1.25-THD) | 1 | |
| 3155235 | 19C SPRING | 1 | |
| 3213145 | 20 SPRING | 1 | |
| 3227493 | 21 LEVER AS-CONTROL | 1 | |
| 3309189 | 22 PLUG | 1 | |
| 3340732 | 23 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 24 BRACKET | 1 | |
| 3362965 | 25 SPRING | 1 | |
| 3694486 | 26 BOLT (M6X1X35-MM) | 2 | |
| 3903729 | 27 LEVER-CONTROL | 1 | |
| 3903731 | 28 SHAFT | 1 | |
| 2177115 | 29 CAP (TAMPER RESISTANT) | 1 | |
| 4237724 | 30 GASKET | 1 | |
| 4656710 | 31 HOUSING | 1 | |
| 3642755 | 32 BOLT (ADJUSTING) | 1 | |
| 5025421 | 33 PIN | 1 | |
| 5029478 | 34 NUT (TAMPER RESISTANT) | 1 | |
| 5039707 | 35 CAP | 1 | |
| 5039731 | 36 SHROUD | 1 |
