System And Components
420-5540 LINES GP-HYDRAULIC -FLUID ENDS/N MLX1-UP
Group No: 420-5540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1G9960 | 1 CLAMP | 14 | |
| 2T2313 | 2 CLAMP | 10 | |
| 5L5502 | 3 FITTING | 1 | |
| 6B9664 | 4 VALVE-AIR RELIEF | 1 | |
| 6W7451 | 5 VALVE (MANUAL BALL) | 1 | |
| 8C1358 | 6 VALVE-BALL | 1 | |
| 8T5224 | 7 GAUGE-PRESSURE | 3 | |
| 0060210 | 8 TEE-PIPE | 1 | |
| 1592313 | 9 VALVE-CHECK | 5 | |
| 1734415 | 10 ELBOW | 5 | |
| 1804793 | 11 VALVE-BALL | 1 | |
| 1804794 | 12 VALVE-RELIEF | 1 | |
| 1804795 | 13 PLUG-SIGHT | 3 | |
| 1804797 | 14 FITTING | 1 | |
| 1849920 | 15 PLUG GP-HYDRAULIC LINES | 1 | |
| 2965728 | 16 CONNECTOR-PIPE | 2 | |
| 3201739 | 17 REGULATOR | 1 | |
| 3201740 | 18 NUT | 1 | |
| 3757732 | 19 BRACKET | 1 | |
| 3757733 | 20 BRACKET AS | 1 | |
| 3757734 | 21 BRACKET AS | 1 | |
| 3916451 | 22 MANIFOLD | 1 | |
| 4205576 | 23 TUBE AS | 1 | |
| 4205577 | 24 HOSE AS | 1 | |
| 4205585 | 25 HOSE AS | 2 | |
| 4205587 | 26 HOSE AS | 1 | |
| 4205588 | 27 HOSE AS | 1 | |
| 4205590 | 28 HOSE AS | 1 | |
| 4205591 | 29 HOSE AS | 1 | |
| 4205592 | 30 HOSE AS | 1 | |
| 4205594 | 31 HOSE AS | 1 | |
| 4205595 | 32 HOSE AS | 1 | |
| 4205596 | 33 HOSE AS | 1 | |
| 4205597 | 34 HOSE AS | 1 | |
| 4205598 | 35 HOSE AS | 1 | |
| 4205599 | 36 HOSE AS | 1 | |
| 4205600 | 37 TUBE AS | 1 | |
| 4205601 | 38 TUBE AS | 1 | |
| 4205602 | 39 TUBE AS | 1 | |
| 4205603 | 40 TUBE AS | 1 | |
| 4205604 | 41 TUBE AS | 1 | |
| 4205648 | 42 HOSE AS | 1 | |
| 4896866 | 43 HOSE AS | 1 | |
| 0026453 | 44 ELBOW | 1 | |
| 0026454 | 45 CONNECTOR | 1 | |
| 0039163 | 46 ELBOW | 1 | |
| 0047270 | 47 FITTING-PIPE | 1 | |
| 0332177 | 48 TEE-PIPE | 1 | |
| 7V5628 | 49 PLATE (TOP) | 14 | |
| 1K6872 | 50 LOCKNUT (1/2-13-THD) | 4 | |
| 2D6235 | 51 LOCKNUT (1/4-20-THD) | 16 | |
| 2K4973 | 52 LOCKNUT (3/8-16-THD) | 1 | |
| 2T1922 | 53 ELBOW | 1 | |
| 2T2317 | 54 PLATE | 5 | |
| 3J1907 | 55 SEAL-O-RING | 1 | |
| 3J7354 | 56 SEAL-O-RING | 6 | |
| 3M7045 | 57 PLUG (3/4-14 NPT-THD) | 2 | |
| 3S8665 | 58 CLIP (LOOP) | 2 | |
| 4J5477 | 59 SEAL-O-RING | 20 | |
| 4K8302 | 60 CLIP (LOOP) | 1 | |
| 4L6454 | 61 BOLT (3/8-16X1-IN) | 1 | |
| 4L9337 | 62 BOLT (3/8-16X1.5-IN) | 2 | |
| 5B7666 | 63 ELBOW | 1 | |
| 5M3062 | 64 BOLT (3/8-16X0.75-IN) | 2 | |
| 5M6213 | 65 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P1076 | 66 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P2566 | 67 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P7468 | 68 CLIP (SLOT) | 3 | |
| 5P7469 | 69 CLIP (TAB) | 3 | |
| 5P8998 | 70 FITTING (1/4-18-THD) | 2 | |
| 5P7470 | 71 CLIP (SLOT) | 1 | |
| 5P7471 | 72 CLIP (TAB) | 1 | |
| 5P7703 | 73 GROMMET (52-MM ID) | 1 | |
| 6B5072 | 74 ADAPTER | 2 | |
| 6V0545 | 75 GROMMET | 3 | |
| 6V5729 | 76 LOCKNUT (7/16-14-THD) | 1 | |
| 6V8397 | 77 SEAL-O-RING | 3 | |
| 6V8398 | 78 SEAL-O-RING | 4 | |
| 6V8628 | 79 ELBOW | 5 | |
| 6V9809 | 80 ELBOW | 1 | |
| 6V9873 | 81 CONNECTOR | 1 | |
| 7J8611 | 82 ELBOW-PIPE | 1 | |
| 7J9108 | 83 SEAL-O-RING | 5 | |
| 7X0264 | 84 BOLT (1/4-20X2.5-IN) | 6 | |
| 7X0269 | 85 BOLT (1/4-20X4-IN) | 10 | |
| 7X5331 | 86 ELBOW | 9 | |
| 8C6866 | 87 CONNECTOR | 6 | |
| 8C6872 | 88 CONNECTOR | 2 | |
| 8C6877 | 89 BOLT (7/16-14X1.75-IN) | 1 | |
| 8M2773 | 90 CLIP (LOOP) | 1 | |
| 8T0315 | 91 SEAL-O-RING | 3 | |
| 8T4205 | 92 WASHER-HARD (7.2X14.5X2-MM THK) | 32 | |
| 8T4223 | 93 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 94 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T5360 | 95 WASHER (12X22.5X2.5-MM THK) | 2 | |
| 8T6761 | 96 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 8T9377 | 97 BOLT (3/8-16X2.25-IN) | 1 | |
| 9S4182 | 98 PLUG (7/16-20-THD) | 1 |
