System And Components
508-5628 HOUSING GP-FRONTS/N W241-UP
Group No: 508-5628
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X1X16-MM) | 4 | |
| 5C2890 | 2 NUT (M6X1-THD) | 1 | |
| 1395511 | 3 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 4 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 5 WASHER | 2 | |
| 1537983 | 6 PIN | 1 | |
| 0951574 | 7 SEAL-O-RING | 1 | |
| 5D1319 | 8 PIN-SPRING | 1 | |
| 1541675 | 9 SEAL | 1 | |
| 1622207 | 10 NUT | 1 | |
| 2177115 | 11 CAP (TAMPER RESISTANT) | 1 | |
| 3081882 | 12 SPRING | 1 | |
| 3081889 | 13 NUT (M10X1.25-THD) | 1 | |
| 3081892 | 14 NUT (M6X1-THD) | 1 | |
| 3081897 | 15 RING | 2 | |
| 3084266 | 16 SHAFT | 1 | |
| 3096729 | 17 SEAL-O-RING | 1 | |
| 3096732 | 18 BOLT | 1 | |
| 3110655 | 19 SPRING | 1 | |
| 3132025 | 20 BOLT-SPECIAL (M10X1.25-MM THD) | 1 | |
| 3155236 | 21 BOLT AS | 1 | |
| 1537987 | 21A WASHER | 1 | |
| 1919297 | 21B NUT (M10X1.25-THD) | 1 | |
| 3155235 | 21C SPRING | 1 | |
| 3214249 | 22 NUT | 1 | |
| 3243400 | 23 LEVER AS-CONTROL | 1 | |
| 3309189 | 24 PLUG | 1 | |
| 3340732 | 25 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 26 BRACKET | 1 | |
| 3647487 | 27 SPRING | 1 | |
| 3694486 | 28 BOLT (M6X1X35-MM) | 2 | |
| 3903729 | 29 LEVER-CONTROL | 1 | |
| 3903731 | 30 SHAFT | 1 | |
| 4237724 | 31 GASKET | 1 | |
| 4257065 | 32 CAP-TAMPER PROOF | 1 | |
| 4656710 | 33 HOUSING | 1 | |
| 3362965 | 34 SPRING | 1 |
