System And Components
498-3124 HOUSING GP-FRONTPART OF 485-8225 ENGINE AR-PRIMARY
Group No: 498-3124
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X16-MM) | 4 | |
| 5C2890 | 2 NUT (M6X1-THD) | 1 | |
| 1395511 | 3 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 4 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 5 WASHER | 2 | |
| 1537983 | 6 PIN | 1 | |
| 1541396 | 7 CLIP (CIRCLE) | 1 | |
| 1622207 | 8 NUT (SPECIAL) | 1 | |
| 2177115 | 9 CAP (TAMPER RESISTANT) | 1 | |
| 2897507 | 10 SEAL-O-RING | 1 | |
| 3081882 | 11 SPRING | 1 | |
| 3081889 | 12 NUT (M10X1.25-THD)(HEX) | 1 | |
| 3081892 | 13 NUT (M6X1-THD) | 1 | |
| 3081897 | 14 RING | 1 | |
| 3084266 | 15 SHAFT | 1 | |
| 3903731 | 16 SHAFT | 1 | |
| 3096729 | 17 SEAL-O-RING | 1 | |
| 4950737 | 18 BOLT | 1 | |
| 3110655 | 19 SPRING | 1 | |
| 3119622 | 20 SPRING | 1 | |
| 3135832 | 21 BOLT AS | 1 | |
| 1537987 | WASHER | 1 | |
| 1919297 | NUT (M10X1.25-THD) | 1 | |
| 3135833 | SPRING | 1 | |
| 5029478 | 22 NUT (HEX) | 1 | |
| 3903729 | 23 LEVER-CONTROL | 1 | |
| 3243397 | 24 LEVER-CONTROL | 1 | |
| 3340732 | 25 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 26 BRACKET | 1 | |
| 3362965 | 27 SPRING | 1 | |
| 3694486 | 28 BOLT (M6X1X35-MM) | 2 | |
| 4237724 | 29 GASKET | 1 | |
| 5025421 | 30 PIN | 1 | |
| 4984597 | 31 SENSOR AS | 1 | |
| 3097591 | 32 HOUSING-FRONT | 1 | |
| 5D1319 | 33 PIN-SPRING | 1 | |
| 1537978 | 34 SEAL (OIL) | 1 | |
| 5039707 | 35 CAP | 1 | |
| 5039731 | 36 SHROUD | 1 |
