Assembly
100%

571-5802 ENCLOSURE GP-ELECTRICALS/N ST71-UP

Group No: 571-5802
Part NumberPart NameQty
10829491 STUD (M10X1.5X270-MM)3
28847252 PLATE2
30239083 SPACER (11X20X30-MM THK)4
32606104 LATCH AS1
1H3244LOCKWASHER4
0966331NUT (M12X1.75-THD)2
3260612WASHER-TAB2
3445673NUT (M6X1-THD)4
34878635 ROD AS1
6V5839WASHER (11X21X2.5-MM THK)1
39238756 LOCKPIN2
57158017 CABINET AS1
57158038 FOAM1
57158049 PLATE AS1
9R2821BOSS (M10X1.5X15-MM)3
571580510 PLATE1
571960411 PLATE AS1
584342812 FOAM1
584342913 FOAM1
584343114 FOAM1
584343215 FOAM1
584343416 FOAM1
584343517 FOAM1
584343618 FOAM1
584343719 FOAM1
584675320 FOAM1
584675521 FOAM1
584675622 PLATE1
584914323 FOAM1
584914424 FOAM1
3B461525 PIN-COTTER2
5P843926 GROMMET1
6V894927 NUT (M10X1.5-THD)3
7X138728 WASHER (10.26X22.22X1.9-MM THK)2
8T412129 WASHER-HARD (11X21X2.5-MM THK)11
8T413730 BOLT (M10X1.5X20-MM)4
8T419131 BOLT (M10X1.5X16-MM)1
8T422332 WASHER-HARD (13.5X25.5X3-MM THK)4
362132033 BOLT (M12X1.75X35-MM)4
8T646634 BOLT (M10X1.5X60-MM)4
8T342635 CHANNEL-TRIM (0.7-M)
345315536 SEAL (130-CM)
345315536A SEAL (183-CM)
345315536B SEAL (288-CM)
