9R-9491 AXLE GP-FRONTS/N 8ZK2748-2748; 8ZK2750-2750; 8ZK2752-2756; 8ZK2758-2759; 8ZK2761-5999

Group No: 9R-9491
Part NumberPart NameQty
9R78211 CAP2
9R03132 HUB AS2
8T66532A STUD16
11439023 SPINDLE AS1
9R19173A BUSHING2
3B84884 FITTING-GREASE (1/8-27 PTF)2
9R85445 WASHER (41X82X10-MM THK)2
9R96156 KINGPIN2
11439037 SPINDLE AS1
9R1917BUSHING2
8T90258 SEAL2
9S79509 CONE-BEARING2
9S358210 CONE-BEARING2
9S358111 CUP-BEARING2
9S794912 CUP-BEARING2
6V814513 SLEEVE2
9R655614 AXLE AS1
9R524614A BUSHING2
009302015 WASHER-THRUST (35X63.5X3.14-MM THK)2
8T399016 NUT (M30X2-THD)2
3B463117 PIN-COTTER2
8B496718 SEAL-O-RING2
9R963119 PIN1
3J190720 SEAL-O-RING1
165899621 WASHER-THRUST (55.5X100.5X5-MM THK)2
8T504122 BOLT (M12X1.75X120-MM)1
8T854923 LOCKNUT (M12X1.75-THD)1
8T419824 BOLT (M10X1.5X100-MM)2
6V774425 LOCKNUT (M10X1.5-THD)2
9S419126 PLUG (9/16-18-THD)1
9X770827 SEAL AS2
9R970228 WASHER (56X100X1.6-MM THK)2
8T417129 BOLT (M6X1X12-MM)1
