System And Components
146-6349 DOOR GP-CABS/N 4AZ1-2823
Group No: 146-6349
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T3985 | 1 KNOB | 1 | |
| 8T4180 | 2 SCREW-MACHINE (M5X0.8X20-MM) | 4 | |
| 8Y6386 | 3 SEAL-HANDLE | 1 | |
| 3E3805 | 4 SEAL (57-CM) | ||
| 1466351 | 5 GLASS | 1 | |
| 1466352 | 6 GLASS | 1 | |
| 1466353 | 7 COVER | 1 | |
| 1466354 | 8 HINGE AS | 2 | |
| 1466347 | RING-RETAINING | 1 | |
| 1466348 | PIN | 1 | |
| 1466356 | 9 PANEL | 1 | |
| 1466357 | 10 GASKET | 1 | |
| 1480617 | 11 STRIKER AS | 1 | |
| 1753325 | 12 HANDLE AS | 1 | |
| 1782566 | 13 LATCH AS-DOOR | 1 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 2 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 3 | |
| 9X2616 | 17 SCREW-SOCKET (M8X1.25X16-MM) | 4 | |
| 9X6155 | 18 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 4 |
