System And Components
342-8529 CONTROL GP-GOVERNORPART OF 341-3024 ENGINE AR
Group No: 342-8529
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 3 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 4 WASHER | 2 | |
| 1537983 | 5 PIN | 1 | |
| 0951574 | 6 SEAL-O-RING | 1 | |
| 3694486 | 7 BOLT (M6X1X35-MM) | 2 | |
| 1622207 | 8 NUT | 1 | |
| 2177115 | 9 CAP (TAMPER RESISTANT) | 1 | |
| 1068916 | 10 BOLT (M6X1X16-MM) | 4 | |
| 4237724 | 11 GASKET | 1 | |
| 3081882 | 12 SPRING | 1 | |
| 3081889 | 13 NUT (M10X1.25-THD) | 1 | |
| 3081892 | 14 NUT (M6X1-THD) | 1 | |
| 3081897 | 15 RING | 2 | |
| 3084266 | 17 SHAFT | 1 | |
| 3903731 | 18 SHAFT | 1 | |
| 3096729 | 19 SEAL-O-RING | 1 | |
| 4950737 | 20 BOLT | 1 | |
| 3110655 | 21 SPRING | 1 | |
| 3155236 | 22 BOLT AS | 1 | |
| 1537987 | 22A WASHER | 1 | |
| 1919297 | 22B NUT (M10X1.25-THD) | 1 | |
| 3155235 | 22C SPRING | 1 | |
| 3177195 | 23 SPRING | 1 | |
| 3193250 | 24 SENSOR-SPEED (TIMING) | 1 | |
| 3214249 | 25 NUT | 1 | |
| 3903729 | 26 LEVER-CONTROL | 1 | |
| 3243400 | 27 LEVER AS-CONTROL | 1 | |
| 3309189 | 28 PLUG | 1 | |
| 4257065 | 29 CAP-TAMPER PROOF | 1 | |
| 3340732 | 30 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 31 BRACKET | 1 | |
| 3362965 | 32 SPRING | 1 |
