System And Components
342-8646 CONTROL GP-GOVERNORType 1
Group No: 342-8646
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 3 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 4 WASHER | 2 | |
| 1537983 | 5 PIN | 1 | |
| 0951574 | 6 SEAL-O-RING | 1 | |
| 3694486 | 8 BOLT (M6X1X35-MM) | 2 | |
| 1622207 | 9 NUT | 1 | |
| 2177115 | 11 CAP (TAMPER RESISTANT) | 1 | |
| 3355578 | 12 BRACKET | 1 | |
| 4237724 | 13 GASKET | 1 | |
| 3081882 | 14 SPRING | 1 | |
| 3081892 | 15 NUT (M6X1-THD) | 1 | |
| 3081897 | 16 RING | 2 | |
| 4257065 | 17 CAP-TAMPER PROOF | 1 | |
| 3214249 | 18 NUT | 1 | |
| 3081901 | 19 CAP | 1 | |
| 3084266 | 20 SHAFT | 1 | |
| 3903731 | 21 SHAFT | 1 | |
| 3110655 | 22 SPRING | 1 | |
| 3155236 | 23 BOLT AS | 1 | |
| 1537987 | 23A WASHER | 1 | |
| 1919297 | 23B NUT (M10X1.25-THD) | 1 | |
| 3155235 | 23C SPRING | 1 | |
| 3647487 | 24 SPRING | 1 | |
| 3340732 | 26 ARM (FRONT HOUSING) | 1 | |
| 3903729 | 27 LEVER-CONTROL | 1 | |
| 3243400 | 28 LEVER AS-CONTROL | 1 | |
| 3081889 | 29 NUT (M10X1.25-THD) | 1 | |
| 3096732 | 30 BOLT | 1 | |
| 3132025 | 31 BOLT-SPECIAL (M10X1.25-MM THD) | 1 | |
| 3362965 | 32 SPRING | 1 | |
| 3309189 | 33 PLUG | 1 | |
| 1068916 | 35 BOLT (M6X1X16-MM) | 4 | |
| 3096729 | 36 SEAL-O-RING | 1 |
