System And Components
338-7279 GOVERNOR GPPART OF 449-2029 CYLINDER BLOCK GP-LONG
Group No: 338-7279
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535592 | 3 NUT (M8X1.25-THD) | 1 | |
| 1536415 | 4 WASHER | 2 | |
| 1537983 | 5 PIN | 1 | |
| 3694486 | 6 BOLT (M6X1X35-MM) | 2 | |
| 1622207 | 7 NUT | 1 | |
| 2177115 | 8 CAP (TAMPER RESISTANT) | 1 | |
| 1068916 | 9 BOLT (M6X1X16-MM) | 4 | |
| 2897507 | 10 SEAL-O-RING | 1 | |
| 4237724 | 11 GASKET | 1 | |
| 3081882 | 12 SPRING | 1 | |
| 3081892 | 13 NUT (M6X1-THD) | 1 | |
| 3081897 | 14 RING | 2 | |
| 3084266 | 16 SHAFT | 1 | |
| 3903731 | 17 SHAFT | 1 | |
| 3096729 | 18 SEAL-O-RING | 1 | |
| 4950737 | 19 BOLT | 1 | |
| 3110655 | 20 SPRING | 1 | |
| 3135832 | 21 BOLT AS | 1 | |
| 1537987 | 21A WASHER | 1 | |
| 1919297 | 21B NUT (M10X1.25-THD) | 1 | |
| 3135833 | 21C SPRING | 1 | |
| 3214249 | 22 NUT | 1 | |
| 3903729 | 23 LEVER-CONTROL | 1 | |
| 3243397 | 24 LEVER-CONTROL | 1 | |
| 3275129 | 25 SPRING | 1 | |
| 4257065 | 26 CAP-TAMPER PROOF | 1 | |
| 3340732 | 27 ARM (FRONT HOUSING) | 1 | |
| 3355578 | 28 BRACKET | 1 | |
| 3362965 | 29 SPRING | 1 |
