System And Components
249-7150 PAN GP-OILS/N CSS1-UP
Group No: 249-7150
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1535933 | 1 SEAL | 1 | |
| 1535936 | 2 WASHER (8.2X14.5X1-MM) | 4 | |
| 1536412 | 3 WASHER | 2 | |
| 1536833 | 4 BOLT (M6X1X13-MM) | 31 | |
| 1536835 | 5 SEAL-O-RING | 1 | |
| 1536838 | 6 BOLT AS | 2 | |
| 1536841 | 7 SEAL-O-RING | 2 | |
| 1536848 | 8 COVER | 1 | |
| 1536849 | 9 SPRING | 1 | |
| 1536850 | 10 COLLAR | 1 | |
| 1536851 | 11 CLIP | 1 | |
| 1536853 | 12 SEAL-O-RING | 1 | |
| 1536881 | 13 BOLT (M8X1.25X18-MM) | 1 | |
| 2965162 | 14 ROTOR | 1 | |
| 1541942 | 15 VALVE-RELIEF (ENGINE OIL PRESSURE) | 1 | |
| 1558060 | 16 TUBE-OIL | 1 | |
| 1558063 | 17 STRAINER | 1 | |
| 1604150 | 18 SHIM (0.1-MM THK) | 1 | |
| 1604151 | SHIM (0.15-MM THK) | 1 | |
| 1604152 | SHIM (0.2-MM THK) | 1 | |
| 1604153 | SHIM (0.5-MM THK) | 1 | |
| 1903828 | 19 TUBE AS-OIL | 1 | |
| 2152604 | 20 GASKET | 1 | |
| 2177358 | 21 CAP-OIL FILLER (ENGINE) | 1 | |
| 2182334 | 22 PLUG-DRAIN (OIL PAN) | 1 | |
| 2295150 | 23 GAUGE AS | 1 | |
| 3107063 | 24 PAN-OIL (ENGINE) | 1 | |
| 2357123 | 25 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE) | 1 | |
| 2497264 | 26 VALVE-DRAIN (ENGINE OIL) | 1 |
