System And Components
469-3254 CYLINDER BLOCK GPS/N CG41-UP
Group No: 469-3254
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1535387 | 1 PLUG | 3 | |
| 1535390 | 2 BALL BEARING | 1 | |
| 1535391 | 3 PLUG | 1 | |
| 1535395 | 4 DOWEL | 2 | |
| 1535396 | 5 PIN | 2 | |
| 1536849 | 6 SPRING | 1 | |
| 1536850 | 7 COLLAR | 1 | |
| 1536851 | 8 CLIP | 1 | |
| 1536853 | 9 SEAL-O-RING | 1 | |
| 1536879 | 10 STUD-HOLLOW | 1 | |
| 1540175 | 11 PLUG | 2 | |
| 1540176 | 12 BEARING-NEEDLE | 1 | |
| 1540177 | 13 BEARING-NEEDLE | 1 | |
| 1540178 | 14 SEAL AS-OIL | 1 | |
| 3260081 | SLEEVE | ||
| 1541942 | 15 VALVE-RELIEF | 1 | |
| 1604150 | 16 SHIM (0.1-MM THK) | 1 | |
| 1604151 | 17 SHIM (0.15-MM THK) | 1 | |
| 1604152 | 18 SHIM (0.2-MM THK) | 1 | |
| 1604153 | 19 SHIM (0.5-MM THK) | 1 | |
| 2175770 | 20 PLUG | 2 | |
| 2211136 | 21 PLUG | 4 | |
| 2944916 | 22 BUSHING | 1 | |
| 3081867 | 23 WASHER-THRUST | 1 | |
| 3081869 | 24 COVER | 1 | |
| 3393012 | 25 ROTOR | 1 | |
| 4237729 | 26 GEAR AS | 1 | |
| 4238257 | 27 GEAR AS | 1 | |
| 1535592 | NUT (M8X1.25-THD) | 1 | |
| 4252047 | 28 ADAPTER | 1 | |
| 4698807 | 29 PIPE AS | 1 | |
| 4698861 | 30 CONNECTOR | 1 | |
| 4722215 | 31 PLUG | 1 | |
| 4770268 | 32 CYLINDER BLOCK AS | 1 | |
| 2379315 | PLUG (SEALING) | 2 | |
| 3664251 | PLUG-SEAL | 5 | |
| 4754305 | CYLINDER BLOCK | 1 | |
| 4724718 | PUMP GP-ENGINE OIL | 1 | |
| 4724722 | SHIM GP | 1 |
