System And Components
Assembly
100%

309-6712 CYLINDER BLOCK GPS/N E6X1-UP

Group No: 309-6712
Part NumberPart NameQty
15353871 PLUG3
15353902 BALL BEARING1
15353913 PLUG1
15353944 DOWEL2
15353955 DOWEL2
48701576 PIN-SPRING2
15354027 DOWEL2
15368388 BOLT AS2
15401759 PLUG3
154017610 BEARING-NEEDLE1
154017711 BEARING-NEEDLE1
154017812 SEAL AS-OIL1
154039313 STUD (M8X1.25X31-MM)3
183116314 STUD (M6X1X43-MM)1
183116415 STUD (M6X1X68-MM)1
215262016 GASKET1
217577017 PLUG (BLANKING)2
221113618 PLUG (BLANKING)4
237931519 PLUG (SEALING)2
366425120 PLUG-SEAL5
294491621 BUSHING (STANDARD)1
3024181BUSHING (0.25-MM US)
3024182BUSHING (0.50-MM US)
322687422 STUD1
339301723 PUMP GP-ENGINE OIL1
