183-1162 ENGINE ARALSO AN ATTACHMENT

Group No: 183-1162
Part NumberPart NameQty
28865391 CAP1
15353872 PLUG2
6B09243 BALL BEARING1
15353914 PLUG1
15359365 WASHER4
15368336 BOLT (M6X1X13-MM)26
15368357 SEAL-O-RING1
15368388 BOLT AS4
15368489 COVER1
153684910 SPRING1
153685011 COLLAR1
153685112 CLIP1
154194213 VALVE-RELIEF1
153685314 SEAL-O-RING1
153687915 STUD-HOLLOW1
153688116 BOLT (M8X1.25X18-MM)2
153798717 WASHER2
154017518 PLUG3
215262019 GASKET1
154194421 HOSE (FUMES DISPOSAL)1
215260422 GASKET1
155806023 TUBE-OIL1
155806324 STRAINER1
155807125 TUBE AS-OIL1
156696326 PAN-OIL1
156697327 SEAL1
160415028 SHIM (0.1-MM THK)1
1604151SHIM (0.15-MM THK)1
1604152SHIM (0.2-MM THK)1
1604153SHIM (0.5-MM THK)1
217577132 SHAFT1
165360533 PLUG-DRAIN (DRAIN)(ENGINE OIL)2
220152334 FILTER AS-ENGINE OIL1
183116335 STUD (M6X1X43-MM)1
183116436 STUD (M6X1X68-MM)1
183116537 PLUG1
183116638 CYLINDER BLOCK GP1
154123139 WASHER-THRUST2
294491640 BUSHING (STANDARD)1
3024181BUSHING (0.25-MM US)1
3024182BUSHING (0.50-MM US)1
156697641 CRANKSHAFT GP1
197055442 PISTON AS3
154087343 PIN1
154087444 RING-RETAINING (INTERNAL)2
154094345 KIT-PISTON RING1
156696746 BEARING AS1
153540246A DOWEL2
154038546B BOLT2
156696847 BEARING AS1
153540247A DOWEL2
154038547B BOLT2
156697048 BEARING AS1
153540248A DOWEL2
154038548B BOLT2
156698049 ROD AS-CONNECTING3
154086949A BUSHING1
154087049B BOLT2
154087149C NUT2
221113650 PLUG (BLANKING)3
153539451 DOWEL2
153539552 DOWEL2
153539653 PIN2
153540254 DOWEL2
154039055 BOLT2
154039356 STUD (M8X1.25X31-MM)2
154039157 PLATE1
156697158 BOLT2
