System And Components
291-9419 CYLINDER BLOCK GP
Group No: 291-9419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1535387 | 1 PLUG | 3 | |
| 6B0924 | 2 BALL BEARING | 1 | |
| 1535391 | 3 PLUG | 1 | |
| 1535394 | 4 DOWEL | 2 | |
| 1535395 | 5 DOWEL | 2 | |
| 1535396 | 6 PIN | 2 | |
| 1535402 | 7 DOWEL | 1 | |
| 1536838 | 8 BOLT AS | 2 | |
| 1540175 | 9 PLUG | 2 | |
| 1540176 | 10 BEARING-NEEDLE | 1 | |
| 1540177 | 11 BEARING-NEEDLE | 1 | |
| 1540178 | 12 SEAL AS-OIL | 1 | |
| 1540391 | 13 PLATE | 1 | |
| 1540393 | 14 STUD (M8X1.25X31-MM) | 3 | |
| 1831163 | 15 STUD (M6X1X43-MM) | 1 | |
| 1831164 | 16 STUD (M6X1X68-MM) | 1 | |
| 2944916 | 17 BUSHING (STANDARD) | 1 | |
| 3024181 | BUSHING (0.25-MM US) | ||
| 3024182 | BUSHING (0.50-MM US) | ||
| 2152620 | 18 GASKET | 1 | |
| 2175770 | 19 PLUG | 2 | |
| 2211136 | 20 PLUG (BLANKING) | 3 |
