System And Components
183-1284 ENGINE ARType 1
Group No: 183-1284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1603506 | 1 BEARING AS | 3 | |
| 1535402 | 1A DOWEL | 2 | |
| 1540385 | 1B BOLT | 2 | |
| 6B0924 | 2 BALL BEARING | 1 | |
| 1535391 | 3 PLUG | 1 | |
| 1535936 | 4 WASHER | 4 | |
| 1536832 | 5 WASHER | 2 | |
| 1536833 | 6 BOLT | 30 | |
| 1536835 | 7 SEAL-O-RING | 1 | |
| 1536838 | 8 BOLT (M6X1X12-MM) | 4 | |
| 1536848 | 9 COVER | 1 | |
| 1536849 | 10 SPRING | 1 | |
| 1536850 | 11 COLLAR | 1 | |
| 1536851 | 12 CLIP | 1 | |
| 1536852 | 13 VALVE-RELIEF | 1 | |
| 1536853 | 14 SEAL-O-RING | 1 | |
| 1536879 | 15 STUD-HOLLOW | 1 | |
| 1536881 | 16 BOLT (M8X1.25X18-MM) | 2 | |
| 1467808 | 17 KIT-BEARING (STANDARD) | 1 | |
| 3079855 | KIT-BEARING (0.25-MM US) | ||
| 3079856 | KIT-BEARING (0.5-MM US) | ||
| 2152620 | 18 GASKET | 1 | |
| 1541941 | 19 ROTOR | 1 | |
| 1541944 | 20 HOSE (FUMES DISPOSAL) | 1 | |
| 2152605 | 21 GASKET | 1 | |
| 1541947 | 22 PIPE-OIL | 1 | |
| 1541948 | 23 STRAINER (OIL PAN) | 1 | |
| 1566973 | 24 SEAL | 1 | |
| 1604150 | 25 SHIM (0.1-MM THK) | 1 | |
| 1604151 | SHIM (0.15-MM THK) | 1 | |
| 1604152 | SHIM (0.2-MM THK) | 1 | |
| 1604153 | SHIM (0.5-MM THK) | 1 | |
| 1541203 | 26 KIT-CRANKSHAFT BEARING (MAIN) | 1 | |
| 1617163 | KIT-CRANKSHAFT BEARING (0.25-MM US) | ||
| 1617164 | KIT-CRANKSHAFT BEARING (0.5-MM US) | ||
| 1535394 | 27 DOWEL | 2 | |
| 1535395 | 28 DOWEL | 2 | |
| 1653580 | 29 SHAFT | 1 | |
| 1653605 | 30 PLUG-DRAIN (DRAIN)(ENGINE OIL) | 2 | |
| 2201523 | 31 FILTER AS-ENGINE OIL | 1 | |
| 1831163 | 32 STUD | 1 | |
| 1831164 | 33 STUD | 1 | |
| 1831165 | 34 PLUG | 1 | |
| 1831168 | 36 BUSHING | 1 | |
| 1831285 | 37 BOLT | 3 | |
| 1831286 | 38 CYLINDER BLOCK GP | 1 | |
| 1603562 | 39 PAN-OIL | 1 | |
| 1831288 | 40 TUBE-OIL | 1 | |
| 1566980 | 41 ROD AS-CONNECTING | 4 | |
| 1540869 | 41A BUSHING | 1 | |
| 1540870 | 41B BOLT | 2 | |
| 1540871 | 41C NUT | 2 | |
| 1603525 | 42 CRANKSHAFT GP | 1 | |
| 1535518 | 42A KEY | 1 | |
| 1541202 | 42B GEAR-CRANKSHAFT (33-TEETH) | 1 | |
| 1535396 | 43 PIN | 2 | |
| 1566967 | 44 BEARING AS | 1 | |
| 1535402 | 44A DOWEL | 2 | |
| 1540385 | 44B BOLT | 2 | |
| 1540176 | 45 BUSHING | 1 | |
| 1540177 | 46 BUSHING | 1 | |
| 1540390 | 47 BOLT | 2 | |
| 1540393 | 48 STUD | 3 | |
| 1566972 | 49 PLATE | 1 | |
| 1566968 | 50 BEARING AS | 1 | |
| 1535402 | 50A DOWEL | 2 | |
| 1540385 | 50B BOLT | 2 | |
| 1566970 | 51 BEARING AS | 1 | |
| 1535402 | 51A DOWEL | 2 | |
| 1540385 | 51B BOLT | 2 | |
| 1541230 | 52 WASHER-THRUST | 1 | |
| 1541231 | 53 WASHER-THRUST | 1 | |
| 1970554 | 54 PISTON AS | 4 | |
| 1540873 | 54A PIN | 1 | |
| 1540874 | 54B RING-RETAINING (INTERNAL) | 2 | |
| 2922475 | 54C KIT-PISTON RING | 1 |
