System And Components
230-9047 PAN GP-OILType 2
Group No: 230-9047
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1535592 | 1 NUT (M8X1.25-THD) | 3 | |
| 1535933 | 2 SEAL (ENGINE OIL FILLER CAP) | 1 | |
| 1535936 | 3 WASHER (8.2X14.5X1-MM) | 2 | |
| 1536412 | 4 WASHER | 2 | |
| 4627276 | 5 GASKET | 1 | |
| 1536833 | 6 BOLT (M6X1X13-MM) | 31 | |
| 1536835 | 7 SEAL-O-RING | 1 | |
| 1536838 | 8 BOLT AS | 2 | |
| 1536841 | 9 SEAL-O-RING | 2 | |
| 1536853 | 14 SEAL-O-RING | 1 | |
| 1536879 | 15 STUD-HOLLOW | 1 | |
| 1536881 | 16 BOLT (M8X1.25X18-MM) | 1 | |
| 1541942 | 18 VALVE-RELIEF (ENGINE OIL PRESSURE) | 1 | |
| 3162275 | 19 TUBE-OIL SUCTION | 1 | |
| 3050584 | 20 STRAINER (ENGINE OIL) | 1 | |
| 1542353 | 21 TUBE AS-OIL | 1 | |
| 1806118 | 23 BOLT (M8X1.25X12-MM) | 1 | |
| 1808435 | 24 BOLT | 1 | |
| 1808444 | 25 BOLT | 3 | |
| 0951708 | 26 SEAL-O-RING | 1 | |
| 1808467 | 27 SPACER | 1 | |
| 2097088 | 28 TUBE AS-OIL GAUGE | 1 | |
| 4235607 | 29 GASKET | 1 | |
| 2177358 | 30 CAP-OIL FILLER (ENGINE) | 1 | |
| 2182333 | 31 PAN-OIL (ENGINE) | 1 | |
| 4236224 | 32 PLUG (DRAIN)(ENGINE OIL PAN) | 2 | |
| 2201523 | 33 FILTER AS-ENGINE OIL | 1 | |
| 2287472 | 34 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE) | 1 | |
| 2309048 | 35 FILLER-OIL | 1 | |
| 1635372 | 36 WASHER (8X15.4X4-MM THK)(8X15.44X4-MM THK) | 1 |
