System And Components
539-0310 CHASSIS ARS/N LJ7939-UP
Group No: 539-0310
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3860756 | 1 CHASSIS AS | 1 | |
| 5390311 | 2 GEAR & BEARING GP-SWING | 1 | |
| 3792801 | 3 LOCK | 1 | |
| 3860582 | 4 SEAL | 1 | |
| 5P8500 | 5 KEY | 1 | |
| 4187793 | 6 WASHER (15.2X23X3.4-MM THK) | 24 | |
| 3860705 | 7 PIN | 1 | |
| 2944826 | 8 BOLT-SOCKET HEAD (M8X1.25X80-MM) | 1 | |
| 3T0852 | 9 LOCKNUT (M8X1.25-THD) | 1 | |
| 3860608 | 10 PIN | 1 | |
| 3792604 | 11 PIN-COTTER | 1 | |
| 3860816 | 12 BRACKET AS | 1 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 2 | |
| 3721079 | 14 WASHER-SPECIAL | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 3860659 | 16 BUSHING | 2 | |
| 3860677 | 17 PIN | 2 | |
| 3860648 | 18 PIN-COTTER | 2 | |
| 3873806 | 19 FRAME & BEARING AS | 1 | |
| 3860641 | 20 SEAL (2-CM EACH) | ||
| 1081781 | 21 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 1 | |
| 3721081 | 22 WASHER (13X19.5X2-MM THK) | 1 | |
| 5390312 | 23 SCREW | 24 | |
| 3727413 | 24 FITTING | 2 | |
| 8M5251 | 25 SEAL-O-RING | 1 | |
| 3731775 | 26 CAP | 2 |
