System And Components
183-1335 ENGINE AR
Group No: 183-1335
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1467808 | 1 KIT-BEARING | 1 | |
| 1535387 | 2 PLUG | 3 | |
| 6B0924 | 3 BALL BEARING | 1 | |
| 1535391 | 4 PLUG | 1 | |
| 1535394 | 5 DOWEL | 2 | |
| 1535395 | 6 DOWEL | 2 | |
| 4870157 | 7 PIN-SPRING | 2 | |
| 1535402 | 8 DOWEL | 2 | |
| 1535936 | 9 WASHER | 4 | |
| 1536412 | 10 WASHER | 2 | |
| 1536833 | 11 BOLT | 30 | |
| 1536835 | 12 SEAL-O-RING | 1 | |
| 1536838 | 13 BOLT (M6X1X12-MM) | 4 | |
| 1536848 | 14 COVER | 1 | |
| 1536849 | 15 SPRING | 1 | |
| 1536850 | 16 COLLAR | 1 | |
| 1536851 | 17 CLIP | 1 | |
| 1536853 | 18 SEAL-O-RING | 1 | |
| 1536879 | 19 STUD-HOLLOW | 1 | |
| 1536881 | 20 BOLT (M8X1.25X18-MM) | 2 | |
| 1540175 | 21 PLUG | 4 | |
| 1540176 | 22 BUSHING | 1 | |
| 1540177 | 23 BUSHING | 1 | |
| 1540178 | 24 SEAL AS-OIL | 1 | |
| 1540181 | 25 CAP AS-BEARING | 1 | |
| 1540386 | 26 CAP AS-BEARING | 1 | |
| 1540388 | 27 CAP AS-BEARING | 1 | |
| 1540389 | 28 CAP AS-BEARING | 1 | |
| 1535402 | DOWEL | 2 | |
| 1540385 | BOLT | 2 | |
| 1540393 | 29 STUD | 3 | |
| 1540867 | 30 ROD AS-CONNECTING | 4 | |
| 1540869 | BUSHING | 1 | |
| 1540870 | BOLT | 2 | |
| 1540871 | NUT | 2 | |
| 2973080 | 31 PISTON AS | 1 | |
| 2171456 | KIT-PISTON RING | 4 | |
| 1540873 | 32 PIN | 4 | |
| 1540874 | 33 RING-RETAINING (INTERNAL) | 8 | |
| 3081852 | 34 CRANKSHAFT AS | 1 | |
| 1535518 | KEY | 1 | |
| 3081853 | GEAR-CRANKSHAFT (33-TEETH) | 1 | |
| 1541203 | 35 KIT-CRANKSHAFT BEARING (MAIN) | 1 | |
| 1541230 | 36 WASHER-THRUST | 1 | |
| 1541231 | 37 WASHER-THRUST | 1 | |
| 1541942 | 38 VALVE-RELIEF (ENGINE OIL PRESSURE) | 1 | |
| 1541944 | 39 HOSE (FUMES DISPOSAL) | 1 | |
| 2934786 | 40 PIPE-SUCTION | 1 | |
| 1541948 | 41 STRAINER (OIL PAN) | 1 | |
| 1542353 | 42 TUBE AS-OIL | 1 | |
| 1566971 | 43 BOLT | 3 | |
| 1540391 | 44 PLATE | 1 | |
| 1604150 | 45 SHIM (0.1-MM THK) | 1 | |
| 1604151 | SHIM (0.15-MM THK) | 1 | |
| 1604152 | SHIM (0.2-MM THK) | 1 | |
| 1604153 | SHIM (0.5-MM THK) | 1 | |
| 2175771 | 49 SHAFT | 1 | |
| 1831163 | 50 STUD | 1 | |
| 1831164 | 51 STUD | 1 | |
| 1831336 | 52 BOLT | 2 | |
| 4235607 | 53 GASKET | 1 | |
| 2152620 | 54 GASKET | 1 | |
| 4236224 | 55 PLUG (DRAIN)(ENGINE OIL) | 1 | |
| 2201523 | 56 FILTER AS-ENGINE OIL | 1 | |
| 2944916 | 57 BUSHING | 1 | |
| 3024181 | BUSHING (0.25-MM US) | 1 | |
| 3024182 | BUSHING (0.50-MM US) | 1 | |
| 3199370 | 59 CYLINDER BLOCK GP | 1 | |
| 3124554 | 60 PAN-OIL | 1 |
