Assembly
100%

290-1120 ALTERNATOR GP-CHARGINGS/N CPT13337-UP

Group No: 290-1120 · Commonality
Part NumberPart NameQty
6I04231 BOLT (M12X1.75X30-MM)1
6I04562 BOLT (M8X1.25X45-MM)1
6I06543 BOLT (M10X1.5X25-MM)1
6I08394 BOLT (M8X1.25X70-MM)2
6I10905 BOLT (M8X1.25X40-MM)1
7W26326 WASHER (8.5X16.8X1.6-MM THK)3
11363497 NUT (M8X1.25-THD)2
12438158 BOLT (M8X1.25X16-MM)4
14097939 BRACKET1
140979410 BRACKET1
140979611 SPACER1
346982612 ALTERNATOR GP-CHARGING (55-AMPERE)1
228739113 PULLEY-ALTERNATOR1
262200414 STRAP1
290111915 BOLT-FLANGE HEAD1
