System And Components
105-2457 PUMP GP-AUXILIARY SEA WATERS/N 8RG117-125
Group No: 105-2457
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1003064 | 1 SHIM (0.381-MM THK) | 1 | |
| 1003063 | SHIM (0.305-MM THK) | 1 | |
| 1003062 | SHIM (0.254-MM THK) | 1 | |
| 1003061 | SHIM (0.127-MM THK) | 1 | |
| 1003065 | 2 BODY | 2 | |
| 1054344 | 3 BODY | 1 | |
| 1003067 | 4 MANIFOLD | 1 | |
| 1003068 | 5 MANIFOLD | 1 | |
| 1003069 | 6 HOUSING | 1 | |
| 1003070 | 7 HOUSING | 1 | |
| 1003071 | 8 SHAFT | 1 | |
| 1003072 | 9 SPACER (SEAL) | 2 | |
| 1003073 | 10 COVER | 1 | |
| 1003074 | 11 IMPELLER | 1 | |
| 1003075 | 12 IMPELLER | 1 | |
| 1003076 | 13 PLATE-PORT | 2 | |
| 1003077 | 14 PLATE-PORT | 2 | |
| 6I9236 | 15 BEARING | 1 | |
| 8T4984 | 16 CLAMP-HOSE | 2 | |
| 1003080 | 17 SEAL | 2 | |
| 1003081 | 18 LOCKNUT | 1 | |
| 1003082 | LOCKWASHER | 1 | |
| 9X2215 | 19 SCREW-HEX HEAD | 3 | |
| 3L6789 | 20 LOCKWASHER | 6 | |
| 3E9854 | BOLT (M8X1.25X20-MM) | 6 | |
| 4M0034 | 21 RING-RETAINING | 1 | |
| 6B1124 | 22 BALL BEARING | 1 | |
| 1003088 | 23 HOSE | 1 | |
| 1003090 | 24 RING-SUPPORT | 1 | |
| 1003091 | 25 SEAL | 2 | |
| 3N8213 | 26 RING | 2 | |
| 1974727 | 27 SEAL AS | 2 | |
| 3N8201 | 28 SEAL-O-RING | 2 | |
| 3N8220 | 29 CLAMP AS | 2 | |
| 3N8221 | 30 CLAMP AS | 2 | |
| 3E7428 | 31 PLUG-PIPE (1/4-18-THD) | 2 | |
| 3N8468 | 32 CLAMP AS | 1 | |
| 1B9575 | BOLT (5/16-18X1.56-IN) | 2 | |
| 5S0003 | NUT (5/16-18-THD) | 2 | |
| 4D7860 | 33 LOCKNUT | 1 | |
| 1046069 | 34 ADAPTER | 1 | |
| 1046641 | 35 LOCKNUT-BEARING (M30X1.5-THD) | 1 |
