System And Components
542-9999 VALVE GP-STEERINGS/N SGW1-UP
Group No: 542-9999
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S2596 | 1 SPRING | 4 | |
| 3J1907 | 2 SEAL-O-RING | 2 | |
| 4J0520 | 4 SEAL-O-RING | 1 | |
| 5J2974 | 5 SEAL-O-RING | 2 | |
| 6E5397 | 6 VALVE GP-SELECTOR (STEERING) | 1 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 5H3193 | PIN-SPRING | 2 | |
| 6E5289 | CONNECTOR | 2 | |
| 6E5291 | SPRING | 2 | |
| 6J6506 | 7 SPACER | 1 | |
| 6J6516 | 8 SHIM (0.01-IN THK) | 8 | |
| 6J6517 | 9 SHIM (0.12-MM THK) | 1 | |
| 6T6052 | 10 PLUG-ORIFICE | 1 | |
| 7J4321 | 11 RETAINER-SPRING | 1 | |
| 8C3206 | 12 FLANGE-HALF | 4 | |
| 8F9206 | 13 SEAL-O-RING | 7 | |
| 8J6815 | 14 PLUG-ORIFICE | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 10 | |
| 8T5005 | 17 BOLT (M10X1.5X70-MM) | 4 | |
| 8T6466 | 18 BOLT (M10X1.5X60-MM) | 2 | |
| 9J9821 | 19 SEAT | 4 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S6154 | 21 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5H3193 | PIN-SPRING | 1 | |
| 7J1089 | PLUG | 1 | |
| 9T7220 | 22 COVER | 1 | |
| 9T8672 | 23 RETAINER | 1 | |
| 1268473 | 24 SPRING | 1 | |
| 1488408 | 25 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1488411 | 26 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1645619 | 27 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 1837263 | 28 PLUG AS | 11 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 4564624 | 29 VALVE GP-RELIEF (STEERING CYLINDER) | 1 | |
| 4564633 | 30 VALVE GP-RELIEF (STEERING PUMP) | 1 | |
| 7X4776 | RING-BACKUP | 2 | |
| 8C3097 | SEAL-O-RING | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 4B9782 | 33 BALL | 4 | |
| 1070269 | 34 BOLT-HEAD (M8X1.25X50-MM) | 1 | |
| 6E4288 | KIT-SEAL (CROSSOVER RELIEF VALVE) | 1 | |
| 6E4753 | KIT-SEAL | 1 |
