System And Components
231-0061 CONTROL GP-AIR & TEMPERATURES/N JMH1-UP; BYR1-UP
Group No: 231-0061
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P4339 | 1 NUT-JAM (7/16-28-THD) | 2 | |
| 7F6998 | 2 LOCKWASHER | 2 | |
| 9G0012 | 3 LAMP (MINIATURE)(14-VOLT) | 1 | |
| 1106109 | 4 KNOB-CONTROL (HEATER) | 2 | |
| 1775288 | 5 HOUSING AS | 1 | |
| 1864141 | 6 FILM (DASH) | 1 | |
| 2310058 | 7 PLATE AS | 1 | |
| 1388454 | 8 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 5 | |
| 1536271 | 9 CABLE AS | 1 | |
| 1438874 | BOOT | 1 | |
| 1571361 | 10 SWITCH AS-ROTARY (TEMPERATURE) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 5C9553 | 11 BOLT (M6X1X16-MM) | 3 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 3 |
