System And Components
486-5178 CYLINDER BLOCK GPPART OF 457-1442, 470-1082, 470-1085 ENGINE AR-PRIMARY
Group No: 486-5178
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4777631 | 1 CYLINDER BLOCK AS | 1 | |
| 4777637 | 2 PIPE AS | 1 | |
| 4865191 | 3 ADAPTER | 1 | |
| 3830256 | 4 GASKET | 1 | |
| 3830303 | 5 PLUG | 1 | |
| 3830432 | 6 CASE AS | 1 | |
| 3830468 | 6A BEARING (STANDARD MAIN BEARINGS) | 2 | |
| 3830430 | BEARING (0.20-MM US) | 2 | |
| 3830431 | BEARING (0.40-MM US) | 2 | |
| 3830447 | 6B BOLT | 2 | |
| 3830446 | 7 GASKET | 1 | |
| 3830532 | 8 COVER | 1 | |
| 3830451 | 9 GASKET | 1 | |
| 3830174 | 10 BOLT | 8 | |
| 3830175 | 11 BOLT | 8 | |
| 3830347 | 12 SEAL (REAR) | 1 | |
| 3830457 | 13 CASE AS | 1 | |
| 3830468 | 13A BEARING (STANDARD MAIN BEARINGS) | 2 | |
| 3830430 | BEARING (0.20-MM US) | 2 | |
| 3830431 | BEARING (0.40-MM US) | 2 | |
| 3830447 | 13B BOLT | 2 | |
| 3830458 | 14 CASE AS | 1 | |
| 3830468 | 14A BEARING (STANDARD MAIN BEARINGS) | 2 | |
| 3830430 | BEARING (0.20-MM US) | 2 | |
| 3830431 | BEARING (0.40-MM US) | 2 | |
| 3830447 | 14B BOLT | 2 | |
| 3830459 | 15 CASE AS | 1 | |
| 3830468 | 15A BEARING (STANDARD MAIN BEARINGS) | 2 | |
| 3830430 | BEARING (0.20-MM US) | 2 | |
| 3830431 | BEARING (0.40-MM US) | 2 | |
| 3830447 | 15B BOLT | 2 | |
| 3830305 | 16 BOLT | 3 |
