System And Components
114-8480 AIR CONDITIONER & MOUNTING GPS/N BAS331-UP
Group No: 114-8480
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6D3479 | 1 CLIP | 1 | |
| 1251647 | 2 LOUVER | 4 | |
| 1579175 | 3 CONTROL GP-AIR & TEMPERATURE | 1 | |
| 9X2044 | 4 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 1579179 | 5 AIR CONDITIONER GP | 1 | |
| 1251721 | 6 DUCT AS | 1 | |
| 8T4908 | 7 BOLT (M8X1.25X25-MM) | 4 | |
| 1251648 | 9 DUCT GP | 1 | |
| 1251720 | 10 DUCT AS | 1 | |
| 1251843 | 11 HOSE AS | 2 | |
| 8T7547 | 13 BOLT (M8X1.25X30-MM) | 5 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 1251722 | 15 DUCT | 1 | |
| 1251723 | 16 DUCT | 1 | |
| 1358352 | 17 CAP | 1 | |
| 8T4199 | 18 BOLT (M8X1.25X12-MM) | 1 | |
| 8M2773 | 19 CLIP (LOOP) | 1 |
