System And Components
222-1276 LINES GP-BUCKET CYLINDERS/N NAD1-3474
Group No: 222-1276
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2093535 | 1 TUBE AS | 1 | |
| 2093536 | 2 TUBE AS | 1 | |
| 2098167 | 3 CLAMP | 1 | |
| 2221297 | 4 HOSE AS | 2 | |
| 6V8398 | 5 SEAL-O-RING | 4 | |
| 2023656 | 6 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9169 | 7 NUT (13/16-16-THD) | 2 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4195 | 9 BOLT (M10X1.5X30-MM) | 1 | |
| 9R1004 | 10 CLIP (TAB) | 2 | |
| 9R1005 | 11 CLIP (SLOT) | 2 |
