System And Components
Assembly
100%

227-0442 LINES GP-PILOT -JOYSTICKS/N SPC1-UP

Group No: 227-0442
Part NumberPart NameQty
4I95211 BAND-MARKER (RED, L1)2
4I95222 BAND-MARKER (YELLOW, L2)2
4I95233 BAND-MARKER (BLUE, L3)2
4I95244 BAND-MARKER (BROWN, L4)2
4I95255 BAND-MARKER (ORANGE, R1)2
4I95266 BAND-MARKER (WHITE, R2)2
4I95277 BAND-MARKER (GREEN, R3)2
4I95288 BAND-MARKER (PURPLE, R4)2
08744029 HOSE AS2
133581310 BAND-MARKER (GRAY, P)4
165952211 VALVE GP-PILOT (TRAVEL)1
168975912 BLOCK1
184933613 SUPPORT3
236283814 PLATE1
236284315 HOSE AS4
236284416 HOSE AS4
236284817 HOSE AS1
245507918 HOSE AS1
255166519 HOSE AS1
255166620 HOSE AS1
099724121 WASHER-HARD (19X34X3-MM THK)8
148833622 CONNECTOR AS15
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8636CONNECTOR1
148836423 ELBOW AS2
3K0360SEAL-O-RING1
6V8398SEAL-O-RING1
6V8625ELBOW1
148836624 ELBOW AS8
6V8397SEAL-O-RING2
6V8987ELBOW1
148837825 ELBOW AS6
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8724ELBOW1
148840726 PLUG AS4
3J1907SEAL-O-RING1
9S4191PLUG (9/16-18-THD)1
164562827 CONNECTOR AS3
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
1076631CONNECTOR-FILTER1
6V916828 NUT (11/16-16-THD)8
7K118129 STRAP-CABLE4
8T412130 WASHER-HARD (11X21X2.5-MM THK)14
8T413631 BOLT (M10X1.5X25-MM)4
8T413732 BOLT (M10X1.5X20-MM)6
8T419133 BOLT (M10X1.5X16-MM)2
8T419834 BOLT (M10X1.5X100-MM)2
