System And Components
523-9563 IDLER GP-FRONT -LHS/N CR53860-UP
Group No: 523-9563
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0951600 | 1 SEAL-O-RING | 2 | |
| 1204636 | 2 NUT (M30X3-THD) | 1 | |
| 1542235 | 3 BOLT (M10X1.25X45-MM) | 2 | |
| 3570221 | 4 FITTING-GREASE | 1 | |
| 4155194 | 5 SEAL-DUST | 1 | |
| 4155199 | 6 SHAFT | 1 | |
| 4155200 | 7 SUPPORT-IDLER | 1 | |
| 4220824 | 8 SEAL GP-DUO-CONE | 2 | |
| 4220826 | 9 PLATE-LOCK | 1 | |
| 4220827 | 10 SUPPORT AS-IDLER | 1 | |
| 4155200 | SUPPORT-IDLER | 1 | |
| 4220830 | 11 SUPPORT | 1 | |
| 4220831 | 12 ROD AS | 1 | |
| 4687299 | 13 IDLER & BEARING AS | 1 | |
| 4687298 | 13A BUSHING | 2 | |
| 5239561 | 14 CYLINDER AS | 1 | |
| 5239562 | 15 SPRING | 1 | |
| 0951604 | 16 SEAL-O-RING | 1 | |
| 0951794 | 17 RING-BACKUP | 1 | |
| 3B5302 | 18 PIN-COTTER | 1 | |
| 5P1075 | 19 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4194 | 21 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9F2247 | 23 PLUG-PIPE (1/8-27-THD) | 1 |
