System And Components
365-5791 PUMP GP-PISTON -PROPELS/N LR21-UP; 2B21-UP
Group No: 365-5791
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M9780 | 1 SEAL-O-RING | 2 | |
| 1124627 | 2 SCREW-LOCK | 2 | |
| 1124628 | 3 SCREW (7/16-20X0.5-IN) | 3 | |
| 3J7354 | 4 SEAL-O-RING | 3 | |
| 1974938 | 5 ORIFICE | 2 | |
| 1676805 | 6 PIN | 2 | |
| 4336472 | 7 ROTATING GP-PUMP | 1 | |
| 4336474 | 8 VALVE GP-PUMP CONTROL | 1 | |
| 9S8004 | 9 PLUG (9/16-18-THD) | 3 | |
| 3J1907 | 10 SEAL-O-RING | 3 | |
| 4336487 | 11 VALVE GP-FLUSHING | 1 | |
| 1124629 | 12 SCREW (3/4-16X0.6-IN) | 1 | |
| 3K0360 | 13 SEAL-O-RING | 1 | |
| 4336483 | 14 COUPLING | 1 | |
| 1177322 | 15 SEAL-RING | 1 | |
| 4230871 | 16 PLATE-WEAR | 1 | |
| 6V3835 | 17 SEAL-O-RING | 1 | |
| 6V3938 | 18 BOLT (M10X1.5X20-MM) | 4 | |
| 2080926 | 19 SEAL-O-RING | 1 | |
| 7R8872 | 20 SEAL-O-RING | 1 | |
| 1124686 | 21 PIN | 1 | |
| 4336473 | 22 HEAD GP-PUMP | 1 | |
| 1124630 | 23 SCREW (1-5/16-THD) | 1 | |
| 7M8485 | 24 SEAL-O-RING | 1 | |
| 0951295 | 25 DOWEL | 1 | |
| 1124641 | 26 SEAL-O-RING | 1 | |
| 4336481 | 27 RING-GUIDE | 2 | |
| 4336482 | 28 KIT-SEAL (PUMP CONTROL VALVE) | 2 | |
| 4336480 | 29 ACTUATOR GP-PUMP | 1 | |
| 6V5586 | SEAL-O-RING | 1 | |
| 8C3080 | SEAL-O-RING | 1 | |
| 8T0267 | 30 BOLT-SOCKET HEAD (M6X1X12-MM) | 4 | |
| 9X6606 | 31 NUT-HEX (M10X1-THD) | 1 | |
| 9T3928 | 32 PLUG AS | 1 | |
| 1878001 | SEAL | 1 | |
| 1124626 | 33 PIN | 1 | |
| 4496151 | 34 ORIFICE | 1 | |
| 4336475 | KIT-SEAL (PISTON PUMP) | 1 |
