System And Components
155-9912 PUMP GP-PISTON -POWER TRAINS/N SAW1-UP
Group No: 155-9912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1614741 | 1 FILTER AS (PISTON PUMP) | 1 | |
| 1835890 | 2 FLANGE | 1 | |
| 1835925 | 3 RING-SEAL | 1 | |
| 1835901 | 4 PLUG | 1 | |
| 1835844 | 5 UNION | 1 | |
| 8T1158 | 6 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 4 | |
| 9R5708 | 7 LOCKWASHER | 2 | |
| 8T0341 | 8 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 9T9522 | 9 FLANGE | 1 | |
| 8T1160 | 10 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 6 | |
| 9X6032 | 11 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 6 | |
| 1835898 | 12 VALVE GP-RELIEF (CROSSOVER/MAKEUP) | 2 | |
| 1178764 | 13 SEAL-O-RING | 2 | |
| 1882871 | 14 BUSHING | 2 | |
| 5K9090 | 15 SEAL-O-RING | 2 | |
| 1151431 | 16 SOLENOID AS (PUMP DISPLACEMENT) | 2 | |
| 1151435 | CONNECTOR | 1 | |
| 1151532 | SEAL | 1 | |
| 1835891 | 17 ACTUATOR GP-PUMP | 1 | |
| 1835837 | 18 SPRING | 1 | |
| 1835882 | 19 BARREL AS | 1 | |
| 9T4582 | 20 RETAINER | 1 | |
| 8U3875 | 21 PLUG | 1 | |
| 9T4906 | 22 RING-RETAINING | 1 | |
| 1064786 | 23 SEAL-RING | 1 | |
| 3E4299 | 24 SEAL-O-RING | 1 | |
| 1835896 | 25 VALVE GP-RELIEF (CHARGE SYSTEM) | 1 | |
| 8T0348 | 26 BOLT-SOCKET HEAD (M16X2X50-MM) | 2 | |
| 1835875 | 27 HOUSING | 1 | |
| 6S3051 | 28 CUP-BEARING | 1 | |
| 1835845 | 29 ADAPTER | 1 | |
| 0058592 | 30 SEAL-O-RING | 1 | |
| 1835895 | 31 VALVE GP-RELIEF (COLD OIL BYPASS) | 1 | |
| 8T6594 | 32 BOLT-SOCKET HEAD (M16X2X35-MM) | 2 | |
| 0951295 | 33 DOWEL | 1 | |
| 1835885 | 34 PLATE | 1 | |
| 9T6072 | 35 SPACER (0.3-MM THK) | 4 | |
| 9T6071 | 36 SPACER (45-MM IDX55-MM ODX1 THK) | 4 | |
| 9T4580 | 37 RETAINER | 1 | |
| 9T5040 | 38 PLUG | 2 | |
| 9T4659 | 39 SHIM (1-MM THK) | 1 | |
| 9T4658 | 40 SHIM (1.05-MM THK) | 1 | |
| 9T4657 | 41 SHIM (1.1-MM THK) | 1 | |
| 9T4656 | 42 SHIM (1.15-MM THK) | 1 | |
| 9T4655 | 43 SHIM (1.2-MM THK) | 1 | |
| 9T4654 | 44 SHIM (1.4-MM THK) | 1 | |
| 9T4653 | 45 SHIM (1.6-MM THK) | 1 | |
| 9T4652 | 46 SHIM (1.8-MM THK) | 1 | |
| 9T4912 | 47 SEAL-LIP TYPE | 1 | |
| 9T4587 | 48 SLEEVE | 1 | |
| 1835884 | 49 SHAFT | 1 | |
| 9T4628 | 50 COVER | 1 | |
| 8T0267 | 51 BOLT-SOCKET HEAD (M6X1X12-MM) | 6 | |
| 1B3909 | 52 CUP-BEARING | 1 | |
| 9T4615 | 53 HOUSING | 1 | |
| 9S4191 | 54 PLUG-O RING | 2 | |
| 3J1907 | 55 SEAL-O-RING | 2 | |
| 0132696 | 56 COUPLING | 1 | |
| 8C3428 | 57 RING-RETAINING | 1 | |
| 1835874 | 58 PUMP GP-CHARGE | 1 | |
| 1835850 | 59 STRAINER | 1 | |
| 1835849 | 60 STRAINER | 1 | |
| 8U0580 | 61 SEAL-O-RING | 2 | |
| 9T4894 | 62 DOWEL | 1 | |
| 1835883 | 63 SWASHPLATE GP (VARIABLE) | 1 | |
| 1835886 | 64 COVER GP-PUMP | 1 | |
| 8T4196 | 65 BOLT (M10X1.5X35-MM) | 10 | |
| 9T4583 | 66 PIN | 2 | |
| 8C3131 | 67 SEAL-O-RING | 2 | |
| 9T5255 | 68 SPRING | 1 | |
| 9T4623 | 69 SPOOL | 1 | |
| 9T4613 | 70 HOUSING | 1 | |
| 8T9521 | 71 SEAL-O-RING | 1 | |
| 9T4881 | 72 RING | 1 | |
| 9W5836 | 73 CONE-BEARING | 1 | |
| 0081902 | 74 CONE-BEARING | 1 |
