Assembly
100%

154-7309 LEVER GP-PROPELS/N AFC1-306; AET1-334

Group No: 154-7309
Part NumberPart NameQty
19438901 CONTROL GP-BLADE1
18637352 PIN-CONNECTOR (16-GA TO 18-GA)4
10288043 KIT-RECEPTACLE (4-PIN)1
4B12834 SCREW-MACHINE (1/4-20X0.875-IN)2
00992585 NUT (1/4-20-THD)2
18631696 SPACER2
18631637 BUSHING1
18631718 BUSHING2
5B31809 NUT (5/16-18-THD)1
031415510 LOCKNUT (5/16-18-THD)1
7X339311 WASHER-HARD (8.3X19X1.83-MM THK)2
140968512 WASHER-SPRING (8.64X22.1X1.9-MM THK)8
171207313 WASHER (8.74X20.58X1.5-MM THK)2
186316214 DISK1
166807215 SPRING-COMPRESSION2
4L125016 LOCKNUT (10-32-THD)3
166807017 BOLT-SOCKET HEAD (10-32X11.18-MM)2
166807118 BEARING-CONNECTING ROD1
8L652119 BOLT (10-32X0.5-IN)1
7X246620 CLIP1
140933721 SWITCH-MICRO1
171284222 BOLT-SOCKET HEAD (M3X0.5X20-MM)2
8T265823 LOCKNUT (M3X0.5-THD)2
186338024 CONTROL GP-HANDLE1
186362625 LEVER1
140933826 BOOT1
8H495927 BOLT (10-32X0.875-IN)2
098360228 SWIVEL1
3K576129 WASHER (0.328X0.62X0.032-IN THK)1
141179430 PIN-COTTER1
166806831 CLAMP-CABLE1
3E986532 LOCKNUT (1/4-20-THD)1
8T420533 WASHER-HARD (7.2X14.5X2-MM THK)1
