System And Components
221-6835 HOUSING GP-FRONTS/N CPT1-6883
Group No: 221-6835
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8736 | 1 KEY-WOODRUFF | 1 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 8 | |
| 6I0254 | 3 BOLT (M8X1.25X30-MM) | 6 | |
| 6I0260 | 4 BOLT (M8X1.25X25-MM) | 1 | |
| 6I0645 | 5 BOLT (M8X1.25X25-MM) | 3 | |
| 6I0789 | 6 BOLT (M10X1.5X60-MM) | 3 | |
| 6I0839 | 7 BOLT (M8X1.25X70-MM) | 6 | |
| 6I0846 | 8 BOLT (M6X1X14-MM) | 2 | |
| 7C4616 | 9 BOLT (M12X1.75X45-MM) | 1 | |
| 1331011 | 10 WASHER | 1 | |
| 0676179 | 11 DOWEL | 1 | |
| 0676897 | 12 HUB-IDLER GEAR | 1 | |
| 0676900 | 13 PLATE-RETAINING | 1 | |
| 0676178 | 14 WASHER-THRUST | 1 | |
| 1407443 | 15 GASKET-COVER | 1 | |
| 1407444 | 16 SHIELD | 1 | |
| 1407445 | 17 DAMPER | 1 | |
| 1603510 | 18 GASKET | 1 | |
| 1836317 | 19 COVER AS-FRONT | 1 | |
| 2880422 | 20 SEAL-CRANKSHAFT | 1 | |
| 2168634 | 21 GEAR-CAMSHAFT (68-TEETH) | 1 | |
| 2168632 | 22 HOUSING-FRONT | 1 | |
| 2514336 | 23 GEAR AS-IDLER (73-TEETH) | 1 | |
| 2528739 | KIT-REPAIR (FRONT COVER, TIMING GEAR) | 1 |
