System And Components
209-5565 CYLINDER BLOCK GPS/N 1ML1-3112
Group No: 209-5565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1138 | 1 BOLT (3/8-24X0.5-IN) | 6 | |
| 1N3762 | 2 PLUG-CUP | 6 | |
| 6I0164 | 3 LINER | 6 | |
| 8T0269 | 4 BOLT-SOCKET HEAD (M6X1X20-MM) | 2 | |
| 6I1074 | 5 VALVE AS (OIL JET) | 6 | |
| 6I0686 | 6 SPRING | 1 | |
| 6I1075 | 7 BALL | 1 | |
| 6I1076 | 8 RETAINER | 1 | |
| 6I4354 | 9 DOWEL | 1 | |
| 7W2501 | 10 PLUG | 1 | |
| 8F2534 | 11 GASKET | 1 | |
| 4943830 | 12 PLUG-FREEZE | 1 | |
| 0358068 | 13 BOLT (5/8-18X3.75-IN) | 14 | |
| 0365802 | 14 BEARING | 1 | |
| 0676002 | 15 DOWEL | 14 | |
| 0676043 | 16 PLUG-SIDE | 3 | |
| 0676805 | 17 PLUG | 1 | |
| 0676808 | 18 PLUG | 1 | |
| 0679520 | 19 SPACER | 6 | |
| 1130309 | 20 BRIDGE | 1 | |
| 1273294 | 21 SHAFT | 1 | |
| 1471978 | 22 DOWEL | 2 | |
| 1483026 | 23 JET AS-PISTON COOLING | 6 |
