System And Components
209-5566 CYLINDER BLOCK GPS/N 7AK4359-UP
Group No: 209-5566
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1138 | 1 BOLT (3/8-24X0.5-IN) | 6 | |
| 3434295 | 2 PLUG | 9 | |
| 8T0269 | 3 BOLT-SOCKET HEAD (M6X1X20-MM) | 2 | |
| 6I1074 | 4 VALVE AS (OIL JET) | 6 | |
| 6I0686 | 4A SPRING | 1 | |
| 6I1075 | 4B BALL | 1 | |
| 6I1076 | 4C RETAINER | 1 | |
| 5H3182 | 8 PIN-SPRING | 1 | |
| 3024757 | 9 PLUG | 1 | |
| 2141668 | 10 WASHER-SPECIAL | 1 | |
| 4943830 | 11 PLUG-FREEZE | 1 | |
| 0S2353 | 12 BOLT (5/8-18X3.75-IN) | 14 | |
| 0365802 | 13 BEARING | 1 | |
| 0676002 | 14 DOWEL | 14 | |
| 0676805 | 15 PLUG | 1 | |
| 0676808 | 16 PLUG | 1 | |
| 0679520 | 17 SPACER | 6 | |
| 1111815 | 18 LINER | 6 | |
| 2490207 | 19 BRIDGE | 1 | |
| 2313497 | 20 SHAFT-IDLER | 1 | |
| 1471978 | 21 DOWEL | 2 | |
| 1483026 | 22 JET AS-PISTON COOLING | 6 | |
| 2152103 | 23 PLUG | 6 | |
| 4203648 | 24 SETSCREW (M8X1.25X10-MM) | 2 |
