System And Components
166-5254 AIR COMPRESSOR GPS/N 5YS1-14381
Group No: 166-5254
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 4 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 1 | |
| 6I0233 | 3 NUT (M12X1.75-THD) | 3 | |
| 6I0260 | 4 BOLT (M8X1.25X25-MM) | 2 | |
| 6I4200 | 5 BOLT (M10X1.5X16-MM) | 2 | |
| 0358017 | 6 UNION | 1 | |
| 0676045 | 7 WASHER (16.25X21.03X1.62-MM THK) | 2 | |
| 2143203 | 8 WASHER (SEALING) | 1 | |
| 1004830 | 9 BOLT (M10X1.5X20-MM) | 1 | |
| 1013917 | 10 WASHER (10.5X21X2-MM THK) | 2 | |
| 1134608 | 11 ADAPTER | 1 | |
| 1134616 | 12 CONNECTOR | 2 | |
| 1243815 | 13 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 14 GEAR (28-TEETH) | 1 | |
| 1263205 | 15 BRACKET | 1 | |
| 1263206 | 16 HUB | 1 | |
| 1263207 | 17 SEAL-O-RING | 1 | |
| 1263208 | 18 BEARING | 1 | |
| 1263209 | 19 GEAR (32-TEETH) | 1 | |
| 1263210 | 20 PLATE | 1 | |
| 1263211 | 21 BOLT | 3 | |
| 1263212 | 22 BOLT (M8X1.25X25-MM) | 4 | |
| 1263216 | 23 STUD | 1 | |
| 1263217 | 24 STUD | 1 | |
| 1263219 | 25 SEAL-O-RING | 1 | |
| 1278281 | 26 CLIP | 1 | |
| 1665255 | 27 AIR COMPRESSOR GP | 1 | |
| 1988262 | 28 COVER AS | 1 | |
| 1988263 | 28A SEAL-O-RING | 1 | |
| 2096824 | 29 HOSE | 1 | |
| 2096825 | 30 ADAPTER | 2 | |
| 2096833 | 31 HOSE | 1 | |
| 2096834 | 32 BRACKET | 1 | |
| 2101077 | 33 PIPE AS | 1 | |
| 1665261 | CRANKSHAFT | 1 | |
| 0676810 | WASHER | 1 | |
| 2096881 | KIT-SEAL (COMPRESSOR) | 1 | |
| 2096882 | KIT-REPAIR (AIR COMPRESSOR PISTON) | 1 | |
| 2096883 | KIT-REPAIR (AIR COMPRESSOR VALVE) | 1 | |
| 2096884 | KIT-REPAIR (AIR COMPRESSOR RING) | 1 |
