System And Components
231-6115 PUMP GP-ENGINE OIL
Group No: 231-6115
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0254 | 1 BOLT (M8X1.25X30-MM) | 3 | |
| 6I0255 | 2 GEAR AS (20-TEETH) | 1 | |
| 0676927 | 2A BUSHING-TERMINAL | 1 | |
| 6I0256 | 3 WASHER | 1 | |
| 6I0257 | 4 PIPE | 1 | |
| 6I0258 | 5 SEAL | 2 | |
| 6I0259 | 6 FLANGE | 1 | |
| 6I0260 | 7 BOLT (M8X1.25X25-MM) | 2 | |
| 6I0650 | 8 BOLT (M10X1.5X65-MM) | 1 | |
| 6I0912 | 9 PUMP AS-ENGINE OIL | 1 | |
| 8N7998 | 10 DOWEL | 1 | |
| 0676928 | 11 CLIP | 1 | |
| 2201510 | 12 HOUSING AS | 1 | |
| 6I0787 | 12A RING-RETAINING | 1 | |
| 7W4648 | 12B SEAT-SPRING | 1 | |
| 7W4782 | 12C PLUNGER | 1 | |
| 1013415 | 12D BOLT | 3 | |
| 1730126 | 12E SPRING | 1 | |
| 1273294 | 13 SHAFT | 1 |
