System And Components
106-6252 TANK & MTG GP-HYDRAULICS/N 1NR1050-UP; 1ZR1000-1017
Group No: 106-6252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 3 | |
| 5D1026 | 3 CLAMP-BAND | 6 | |
| 5V9155 | 4 CLAMP-HOSE | 2 | |
| 7K1181 | 5 STRAP-CABLE | 1 | |
| 9M0164 | 6 CLAMP-HOSE | 2 | |
| 9R9925 | 7 BREATHER-HYDRAULIC (INLINE) | 1 | |
| 1125369 | 8 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 1197749 | 9 HOSE | 1 | |
| 1209926 | 10 CLAMP | 2 | |
| 1220051 | 11 TANK GP-HYDRAULIC | 1 | |
| 1221160 | 12 GAUGE AS-LIQUID LEVEL | 1 | |
| 7X4782 | SEAL-O-RING | 1 | |
| 1367876 | GLASS | 1 | |
| 1368059 | RING-RETAINING | 1 | |
| 1230867 | 13 CAP-FILLER (HYDRAULIC OIL) | 1 | |
| 1518753 | 14 TUBE | 1 | |
| 1394068 | 15 TUBE | 1 | |
| 1409451 | 16 TUBE AS | 1 | |
| 1631491 | 17 TANK-EXPANSION | 1 | |
| 0618844 | 18 GROMMET | 1 | |
| 3F1240 | 19 GROMMET | 1 | |
| 5C7261 | 20 NUT (M8X1.25-THD) | 1 | |
| 8T4179 | 22 BOLT (M12X1.75X20-MM) | 4 | |
| 8T4191 | 23 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 27 BOLT (M8X1.25X25-MM) | 3 | |
| 9X2125 | 28 BOLT-LOCKING (M10X1.5X25-MM) | 3 | |
| 5P1695 | 29 HOSE (54-CM) | ||
| 5P1442 | 30 HOSE (33-CM) | ||
| 5P1442 | 31 HOSE (21-CM) | ||
| 5P1505 | 32 HOSE (36-CM) | ||
| 5P1505 | 33 HOSE (94-CM) | ||
| 5P1505 | 34 HOSE (26-CM) |
