197-3872 TURBOCHARGER GPS/N 7BJ67001-99999

Group No: 197-3872
Part NumberPart NameQty
6I02201 GASKET1
6I05633 NUT (M10X1.5-THD)4
6I05724 BOLT (M8X1.25X20-MM)2
5D10266 CLAMP-BAND2
8T67037 CLAMP-HOSE2
10527408 BOLT (M8X1.25X40-MM)8
10689169 BOLT (M6X1X16-MM)2
114259010 CONNECTION1
124381511 BOLT (M8X1.25X16-MM)1
138204312 WASHER2
139700913 MANIFOLD AS-EXHAUST1
148713213A FERRULE2
143453415 HOSE1
162208816 GASKET2
219233017 HOSE1
146184118 BOLT4
219232921 MANIFOLD-AIR INLET1
148713522 TUBE1
101392122A CLIP1
148713624 TUBE1
148713925 CONNECTION1
219977326 TURBOCHARGER GP1
149423627 STUD (M10X1.5X37-MM)4
154804428 CLIP1
162159129 TUBE AS1
224897829A FITTING-COMPRESSION2
146426229B NUT2
164401930 CLIP1
174963831 BOLT (M10X1.5X30-MM)8
148713832 BOLT1
194539033 GASKET-MANIFOLD1
6I063134 BOLT (M6X1X12-MM)2
138206535 GASKET1
2600123SEAL GP1
