System And Components
244-5597 AIR COMPRESSOR GPS/N 3562283-UP
Group No: 244-5597
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 4 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 2 | |
| 1840983 | 3 NUT-HEX FLANGE (M12X1.75-THD) | 3 | |
| 6I4200 | 4 BOLT (M10X1.5X16-MM) | 2 | |
| 0358017 | 5 UNION | 1 | |
| 0358063 | 6 PLUG | 1 | |
| 0676045 | 7 WASHER (16.25X21.03X1.62-MM THK) | 2 | |
| 1004461 | 8 BOLT (M10X1.5X50-MM) | 1 | |
| 1004830 | 9 BOLT (M10X1.5X20-MM) | 1 | |
| 1134608 | 10 ADAPTER | 1 | |
| 1134616 | 11 CONNECTOR | 2 | |
| 1243815 | 12 BOLT (M8X1.25X16-MM) | 3 | |
| 1263205 | 13 BRACKET | 1 | |
| 1263206 | 14 HUB | 1 | |
| 1263207 | 15 SEAL-O-RING | 1 | |
| 1263208 | 16 BEARING | 1 | |
| 1263210 | 17 PLATE | 1 | |
| 9X6032 | 18 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 3 | |
| 1263212 | 19 BOLT (M8X1.25X25-MM) | 4 | |
| 1263216 | 20 STUD | 1 | |
| 1263217 | 21 STUD | 1 | |
| 1263219 | 22 SEAL-O-RING | 1 | |
| 1665262 | 23 BRACKET | 1 | |
| 1665264 | 24 HOSE | 1 | |
| 1988262 | 25 COVER AS | 1 | |
| 1988263 | 25A SEAL-O-RING | 1 | |
| 2096824 | 26 HOSE | 1 | |
| 2096825 | 27 ADAPTER | 2 | |
| 2143204 | 28 GEAR-IDLER (28-TEETH) | 1 | |
| 2143205 | 29 SPACER (10.32X19.05X6.35-MM THK) | 1 | |
| 2143206 | 30 GEAR (34-TEETH) | 1 | |
| 4511179 | 31 COMPRESSOR | 1 | |
| 2445601 | 32 TUBE AS | 1 | |
| 0676264 | 32A FITTING-FLARED | 2 | |
| 0676265 | 32B FITTING-BRASS | 2 | |
| 1053154 | 32C CLIP | 1 | |
| 3665914 | 33 PISTON AS | 1 | |
| 2096881 | KIT-SEAL (COMPRESSOR)(AIR) | 1 | |
| 2096883 | KIT-REPAIR (AIR COMPRESSOR VALVE) | 1 |
