System And Components
415-7115 HOUSING GP-FRONTS/N 2W21-UP; G9F1-UP
Group No: 415-7115
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0650 | 1 BOLT (M10X1.5X65-MM) | 3 | |
| 7C4616 | 2 BOLT (M12X1.75X45-MM) | 1 | |
| 0676179 | 3 DOWEL | 1 | |
| 1003751 | 4 BOLT (M8X1.25X65-MM) | 5 | |
| 1013895 | 5 BOLT (M8X1.25X35-MM) | 2 | |
| 1243815 | 6 BOLT (M8X1.25X16-MM) | 10 | |
| 1331011 | 7 WASHER | 1 | |
| 4257103 | 8 GEAR (68-TEETH) | 1 | |
| 2323666 | 9 WASHER-THRUST | 1 | |
| 2773012 | 10 GASKET-COVER | 1 | |
| 2773013 | 11 SEAL | 1 | |
| 3460408 | 12 PLATE | 1 | |
| 3983296 | 13 CASE-GEAR | 1 | |
| 6I0217 | 14 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0645 | 15 BOLT (M8X1.25X25-MM) | 4 | |
| 2323657 | 16 COVER AS-FRONT | 1 | |
| 2258287 | 16A GASKET | 1 | |
| 3240444 | 17 HUB-IDLER GEAR | 1 | |
| 3460407 | 18 GEAR-IDLER | 1 |
