System And Components
258-7556 AIR COMPRESSOR GP
Group No: 258-7556
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 4 | |
| 1840983 | 2 NUT-HEX FLANGE (M12X1.75-THD) | 2 | |
| 6I0260 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 2733691 | 4 BOLT (M8X1.25X80-MM) | 1 | |
| 6I4200 | 5 BOLT (M10X1.5X16-MM) | 2 | |
| 0358017 | 6 UNION | 1 | |
| 2733690 | 7 BOLT | 1 | |
| 1022073 | 8 SEAL-O-RING | 1 | |
| 1134608 | 9 ADAPTER | 1 | |
| 1138076 | 10 PIN | 1 | |
| 1263219 | 11 SEAL-O-RING | 1 | |
| 4511179 | 12 COMPRESSOR | 1 | |
| 1988262 | 13 COVER AS | 1 | |
| 1988263 | SEAL-O-RING | 1 | |
| 2096825 | 14 ADAPTER | 2 | |
| 2143203 | 15 WASHER (SEALING) | 1 | |
| 2474928 | 16 WASHER (16.5X20.5X1.6-MM THK) | 2 | |
| 2592611 | 17 HOSE | 1 | |
| 2592612 | 18 HOSE | 1 | |
| 2592613 | 19 TUBE AS | 1 | |
| 2931877 | 20 ADAPTER GP-AIR COMPRESSOR | 1 | |
| 2592614 | 21 BRACKET | 1 | |
| 2592623 | 22 GEAR (34-TEETH) | 1 | |
| 3665914 | 23 PISTON AS | 1 | |
| 2096883 | KIT-REPAIR (AIR COMPRESSOR VALVE) | 1 |
