Assembly
100%

339-0145 RADIATOR GPS/N GT81-UP; GT91-UP

Group No: 339-0145
Part NumberPart NameQty
14047671 CLAMP-HOSE2
25853092 BRACKET GP-RADIATOR1
25853553 HOSE (INLET)1
25853564 HOSE (OUTLET)1
26046325 MOUNT AS2
26204956 CLAMP2
26305917 RADIATOR AS1
26463968 FAN (7-BLADE)1
38289069 BRACKET1
1371303NUT6
366182110 BOLT-FLANGE HEAD (M8X1.25X12-MM)1
8T038911 LOCKNUT (M10X1.5-THD)1
8T412112 WASHER-HARD (11X21X2.5-MM THK)11
8T413714 BOLT (M10X1.5X20-MM)2
8T418215 BOLT (M10X1.5X45-MM)2
8T418616 BOLT (M10X1.5X40-MM)6
8T422417 WASHER-HARD (8.8X16X2-MM THK)4
8T754718 BOLT (M8X1.25X30-MM)4
258530719 BRACKET-RADIATOR1
260463320 MOUNT-ISOLATOR1
8T038921 LOCKNUT (M10X1.5-THD)1
8T412122 WASHER-HARD (11X21X2.5-MM THK)1
