System And Components
166-5265 AIR COMPRESSOR GP -SAES/N 7MS2382-UP
Group No: 166-5265
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1604826 | 1 CLAMP-HOSE | 4 | |
| 6B0933 | 2 SPACER (10.31X19.05X6.35-MM THK) | 1 | |
| 6I0217 | 3 BOLT (M8X1.25X20-MM) | 2 | |
| 1840983 | 4 NUT-HEX FLANGE (M12X1.75-THD) | 3 | |
| 6I0646 | 5 BOLT (M10X1.5X14-MM) | 1 | |
| 6I4200 | 6 BOLT (M10X1.5X16-MM) | 2 | |
| 7M7410 | 7 PLUG-PIPE | 1 | |
| 0358017 | 8 UNION | 1 | |
| 2143203 | 9 WASHER (SEALING) | 1 | |
| 1004461 | 10 BOLT (M10X1.5X50-MM) | 1 | |
| 1004830 | 11 BOLT (M10X1.5X20-MM) | 1 | |
| 1134616 | 12 CONNECTOR | 2 | |
| 1243815 | 13 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 14 GEAR (28-TEETH) | 1 | |
| 1263205 | 15 BRACKET | 1 | |
| 1263206 | 16 HUB | 1 | |
| 1263207 | 17 SEAL-O-RING | 1 | |
| 1263208 | 18 BEARING | 1 | |
| 1263209 | 19 GEAR (32-TEETH) | 1 | |
| 1263210 | 20 PLATE | 1 | |
| 9X6032 | 21 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 3 | |
| 1263212 | 22 BOLT (M8X1.25X25-MM) | 4 | |
| 1263216 | 23 STUD | 1 | |
| 1263217 | 24 STUD | 1 | |
| 1263219 | 25 SEAL-O-RING | 1 | |
| 4511179 | 26 COMPRESSOR | 1 | |
| 1665262 | 28 BRACKET | 1 | |
| 1665263 | 29 PIPE AS | 1 | |
| 1053154 | 32 CLIP | 1 | |
| 1665264 | 33 HOSE | 1 | |
| 1988262 | 34 COVER AS | 1 | |
| 1988263 | 35 SEAL-O-RING | 1 | |
| 2096824 | 36 HOSE | 1 | |
| 2096825 | 37 ADAPTER | 2 | |
| 2474928 | 38 WASHER (16.5X20.5X1.6-MM THK) | 2 | |
| 3665914 | 39 PISTON AS | 1 | |
| 2096881 | KIT-SEAL (COMPRESSOR) | 1 | |
| 2096882 | KIT-REPAIR (AIR COMPRESSOR PISTON) | 1 | |
| 2096883 | KIT-REPAIR (AIR COMPRESSOR VALVE) | 1 |
