System And Components
147-5460 CAMSHAFT GP
Group No: 147-5460
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3240444 | 1 HUB-IDLER GEAR | 1 | |
| 6I0789 | 2 BOLT (M10X1.5X60-MM) | 3 | |
| 0676900 | 3 PLATE-RETAINING | 1 | |
| 6I4350 | 4 GEAR AS (27-TEETH) | 1 | |
| 0676927 | 5 BUSHING-TERMINAL | 1 | |
| 0676928 | 6 CLIP | 1 | |
| 6I0256 | 7 WASHER | 1 | |
| 6I0217 | 8 BOLT (M8X1.25X20-MM) | 8 | |
| 6I0260 | 9 BOLT (M8X1.25X25-MM) | 4 | |
| 1280990 | 10 CAMSHAFT | 1 | |
| 0676179 | 11 DOWEL | 1 | |
| 7W4842 | 12 WASHER-THRUST | 1 | |
| 0676135 | 13 KEY-WOODRUFF (CAMSHAFT) | 1 | |
| 9Y2633 | 14 GEAR-CAMSHAFT (56-TEETH) | 1 | |
| 7C4616 | 15 BOLT (M12X1.75X45-MM) | 1 | |
| 0925499 | 16 WASHER (13X60X8-MM) | 1 | |
| 2W1529 | 17 GEAR AS-IDLER (63-TEETH) | 1 | |
| 0676899 | 18 BUSHING-IDLER GEAR | 2 |
