Assembly
100%

214-4029 AIR COMPRESSOR GPS/N 3561-332

Group No: 214-4029
Part NumberPart NameQty
5D10261 CLAMP-BAND4
6I02172 BOLT (M8X1.25X20-MM)1
6I02333 NUT (M12X1.75-THD)3
6I06464 BOLT (M10X1.5X14-MM)1
6I42005 BOLT (M10X1.5X16-MM)1
7M74106 PLUG-PIPE1
03580177 UNION2
06760458 WASHER (16.25X21.03X1.62-MM THK)2
10044619 BOLT (M10X1.5X50-MM)1
100483010 BOLT (M10X1.5X20-MM)1
113461611 CONNECTOR2
124381512 BOLT (M8X1.25X16-MM)3
126320513 BRACKET1
126320614 HUB1
126320715 SEAL-O-RING1
126320816 BEARING1
126321017 PLATE1
126321118 BOLT3
126321219 BOLT (M8X1.25X25-MM)4
126321620 STUD1
126321721 STUD1
126321922 SEAL-O-RING1
166525523 AIR COMPRESSOR GP1
166526224 BRACKET1
166526325 PIPE AS1
105315425A CLIP1
166526426 HOSE1
198826227 COVER AS1
198826327A SEAL-O-RING1
209682428 HOSE1
209682529 ADAPTER2
214320330 WASHER (SEALING)1
214320431 GEAR-IDLER (28-TEETH)1
214320532 SPACER (10.32X19.05X6.35-MM THK)1
214320633 GEAR (34-TEETH)1
