System And Components
551-6578 DOOR GP-ACCESS -RIGHTPART OF 562-2467 COUNTERWEIGHT GP
Group No: 551-6578
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3335726 | 1 BUMPER | 2 | |
| 3445673 | 2 NUT (M6X1-THD) | 4 | |
| 3445674 | 3 NUT (M8X1.25-THD) | 3 | |
| 3B4611 | 4 PIN-COTTER | 1 | |
| 5107331 | 5 DOOR AS-ACCESS (RIGHT) | 1 | |
| 5114470 | BRACKET AS | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5159434 | PLATE-HINGE | 2 | |
| 5150726 | 6 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5150729 | 7 BUSHING | 2 | |
| 5200780 | 8 HINGE | 1 | |
| 1495933 | 9 SEAL (51.5-CM EACH) | ||
| 1495933 | 9A SEAL (63.5-CM) | ||
| 5487980 | 10 LATCH AS | 1 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7S5757 | 12 RING-RETAINING | 1 | |
| 7X0579 | 13 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 7X7729 | 14 WASHER (11X25X3-MM THK) | 2 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T7547 | 17 BOLT (M8X1.25X30-MM) | 1 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 |
